Gemü 567 BioStar control Betriebsanleitung Seite 66

7 Dimensions
7.2.11 Clamp without bypass code 88
DN
Seat L
size
(code)
15 A
45
B
45
C
45
D
45
20 A
45
B
45
C
45
D
45
E
45
G
45
25 H
55
Dimensions in mm
1) Connection type
Code 88: Clamp ASME BPE
2) Valve body material
Code 41: 1.4435 (316L), block material
Code 43: 1.4435 (BN2), block material, Δ Fe < 0.5%
GEMÜ 567
L
LE1 H1
d1
d3
□ E Ø z
75 2
75 4
75 6
75 8
75 2
75 4
75 6
75 8
75 10
75 15
95 25
Connection type code 88 1)
Material code 41, 43 2)
LE1 LE2 H1
59.8 74.20 18.2
59.8 73.20 18.2
59.8 72.20 18.2
59.8 71.20 18.2
56.5 77.38 21.4
56.5 76.38 21.4
56.5 75.38 21.4
56.5 74.38 21.4
56.5 73.38 21.4
56.5 70.88 21.4
66.8 87.60 26.3
66 / 88
H2 cz Ø d1
41.20 3.70 9.40
40.20 2.70 9.40
39.20 1.70 9.40
38.20 0.70 9.40
44.38 6.88 15.75
43.38 5.88 15.75
42.38 4.88 15.75
41.38 3.88 15.75
40.38 2.88 15.75
37.88 0.38 15.75
48.60 1.10 22.10
