Gemü 567 BioStar control Betriebsanleitung Seite 57

DN
Seat L
size
(code)
E
45
G
45
20 H
45
25 H
45
J
45
Dimensions in mm
1) Connection type
Code 17: Spigot EN 10357 series A (formerly DIN 11850 series 2)/DIN 11866 series A
2) Valve body material
Code 41: 1.4435 (316L), block material
Code 43: 1.4435 (BN2), block material, Δ Fe < 0.5%
7.2.3 Spigot without bypass code 59
c
DN
Seat L
size
(code)
15 A
45
B
45
C
45
D
45
20 A
45
B
45
C
45
www.gemu-group.com
□ E c
75 20
75 20
75 20
75 20
75 20
L
s
LE
H1
d
□ E c
75 20
75 20
75 20
75 20
75 20
75 20
75 20
Connection type code 17 1)
Material code 41, 43 2)
Ø z LE H1
10 43.5 21.5
15 43.5 21.5
6 47.5 17.5
2 46.5 18.5
4 46.5 18.5
Connection type code 59 1)
Material code 41, 43 2)
Ø z LE H1
2 46.8 18.2
4 46.8 18.2
6 46.8 18.2
8 46.8 18.2
2 48.6 21.4
4 43.6 21.4
6 43.6 21.4
57 / 88
H2 cz Ø d
40.5 3.0 19
38.0 0.5 19
38.6 1.1 10
41.6 4.1 13
40.6 3.1 13
H2 cz Ø d
41.20 3.70 12.70
40.20 2.70 12.70
39.20 1.70 12.70
38.20 0.70 12.70
44.38 6.88 19.05
43.38 5.88 19.05
42.38 4.88 19.05
7 Dimensions
s
1.5
1.5
1.0
1.5
1.5
s
1.65
1.65
1.65
1.65
1.65
1.65
1.65
GEMÜ 567
