5 Order data
Order option
4 Connection type
5 Valve body material
6 Seal material
7 Control function
8 Actuator version
9 Control characteristic
10 Kv value
11 Special specification
12 Special version
Order example with bypass
Order option
1 Type
2 DN
3 Body configuration
4 Connection type
5 Valve body material
6 Seal material
7 Control function
8 Actuator version
9 Control characteristic
10 Kv value
11 Bypass actuator version
12 Special specification
13 Special version
GEMÜ 567
Code
17 Spigot EN 10357 series A (formerly DIN 11850 series 2)/DIN 11866
series A
41 1.4435 (316L), block material
5 Actuator seal PTFE / seat seal PTFE
0 Manually operated (MO)
2 MB Actuator size 2,
stainless steel handwheel,
with seal adjuster and stroke limiter, locking device to prevent
opening/closing,
mounting for proximity switches M 8x1
G Modified equal-percentage
G1 4.1 m³/h
1536 Ra ≤ 0.4 µm (15 µin.) for media wetted surfaces,
in accordance with DIN 11866 H4,
mechanically polished internal
M Special version for 3A
Code
567 Control valve
15 DN 15
M 2-way angle body with bypass
17 Spigot EN 10357 series A (formerly DIN 11850 series 2)/DIN 11866
series A
41 1.4435 (316L), block material
55 Actuator seal PTFE / seat seal PTFE / bypass seal PTFE
bypass diaphragm code 54
0 Manually operated (MO)
2 MB Actuator size 2,
stainless steel handwheel,
with seal adjuster and stroke limiter, locking device to prevent
opening/closing,
mounting for proximity switches M 8x1
G Modified equal-percentage
G1 4.1 m³/h
S0 Manually operated, with seal adjuster, diaphragm size 8,
1536 Ra ≤ 0.4 µm (15 µin.) for media wetted surfaces,
in accordance with DIN 11866 H4,
mechanically polished internal
M Special version for 3A
