Commissioning/Decommissioning
Fig. 19
6.4.2

Assembling the dummy plate

The following steps are necessary in order to assemble the
dummy plate:
1. Observe the point "Disassembly" on page 36.
2. Attach the dummy plate (30) under the support ring (28) and
fasten it to the main housing (1) using four tapping screws
(103). See "Fig. 12" on page 27 and See "Fig. 13" on page
27.
