Spokey Hadar Bedienungsanleitung Seite 7

24 Body Arm cover 2(Upper)
25 Body Arm cover 1(Bottom)
26 Body Arm cover 2(Bottom)
27 Handlebar cover(L)
28 Handlebar cover(R)
29 Rotary hand bolt
30 T-shaped rotary knob M8x30
31 Magnetic sensor
32 Console communication wire
33 Resistance adjust knob wire
34 Resistance adjust knob
35 Handle pulse connection wire
36 Console outset
INSTALLATION INSTRUCTIONS (Drawings – p. 39)
STEP 1 Attach the front stabilizer (2) to the main frame (1) with curved
washer(40), spring washer(39) and Allen C.K.S. half thread screw(38).
STEP 2 Attach the rear stabilizer (3) to the main frame (1) with curved
washer(40), spring washer(39) and Allen C.K.S. half thread screw(38).
STEP 3
1. Attach the Upright post decoration strip(89)
post(4),take upright post cover(14) off from the main frame(1) and cover it
on the upper upright post(4).
2. Connect motor communication wire(31) and console communication
wire(32),connect the resistance adjust knob wire(33) and resistance adjust
knob(34).
3. Attach upper upright post(4) to the main frame(1) with flat
washer(41), spring washer(39), Allen C.K.S. full thread screw(42) and
flat washer(40), spring washer(39), Allen C.K.S. half thread screw(44)
and Allen C.K.S. half thread screw(40), curved washer(42), Hex self-
locking nut(43).
4. Attach upright post cover(14) to the main frame(1).
5. Attach bottle holder(15) to upper upright post(4) with Philips pan
head full thread screw(45).
6. Attach the axle(16) and Upright post decoration strip(89) to the upright
post(4).
Tip: Put the communication wires and resistance adjust knob wire
into the upright post,and make sure all screws are in the hexagonal hole
before tighten all the bolts.
STEP 4
1. Attach the wave spring washer(47) to the axle(16),attach the body
arm set to the axle(16), tighten with the flat washer(40) and Allen C.K.S.
full thread screw(44).
STEP 5
1. Attach Body arm(L)(8) to Body arm set(7),tighten
washer(41), Allen C.K.S. half thread screw(48),and Hex self-locking
nut(43).
2. Attach the Body Arm cover 1(Upper) （ 23 ） and Body Arm cover
2(Upper)（ 24）to the Body arm(L)(8),tighten with Philips C.K.S. self-
tapping screw(45).
3. Attach the Body arm(R)(9) same as above steps.
Moving the device
Raise the trainer carefully onto its transport wheels (Picture – p. 45) and move to a given place, holding it on both sides.
Resistance adjustment
The function of intensity regulation allows you to change pedal resistance.
High resistance requires a greater effort during pedalling while a low one
reduces the needed effort. Resistive force can be regulated by means of
Levelling
Before you start exercising, it is recommended to verify whether the bike is positioned correctly.
Level the equipment with the knobs of the rear stabilizer.
www.spokey.pl
Philips C.K.S. full head screw
2 56
M4x10
Philips C.K.S. full head screw
2 57
M5x10
2 58 Fixed magnetic induction
Circlip shaft Φ12
1 59
Magnetic control fixed axle
1 60
Φ12x50
Wheels Φ55x25.8
1 61
Allen C.K.S. hollow screw
1 62
Φ8x33xM6x15
1 63 End cap
1 64 Feet pad
1 65 Hex nut M8
Allen C.K.S. full thread screw
1 66
M8x120
Idler connecting shaft Φ15x30
2 67
Tension pulley Φ43.5x25.5
2 68
to the upper upright
with Curved
4 88
4 89
1 90
2 91
1 92
2 93
2 94
4 95
4 96
2 97
1 98
1 99
1
Tip: Make sure all screws are in the hexagonal hole before tighten all the
bolts.
STEP 6
1. Attach the Pedal(L)（17 ） to the Pedal supporter(L/R)(10),tighten with
carriage screw(49), Flat washer(50),and Hex locking nut(51).
2. Attach the Pedal(R)(18) to the Pedal supporter(L/R)(10) as the same
way. Tip: Make sure all screws are in the hexagonal hole before tighten all
the bolts.
STEP 7
1. Attach the Wave spring washer(47) to the axle A1 of main frame(1),and
attach the axle bushing A2 of Pedal supporter(L/R)(10) to the axle A1,
tighten with the Flat washer (40) and Allen C.K.S. full thread screw(44).
2. Attach the U shape plate A3 of Pedal supporter(L/R)(10) to the axle
bushing A4 of main frame(1),tighten with Allen C.K.S. hollow screw(52),
Flat washer(53),and Allen C.K.S. full thread screw(54).
3. Attach the Body Arm cover 1(25) and Body Arm cover 2(26) to the Pedal
supporter(L/R)(10),tighten with Philips C.K.S. self-tapping screw(45).
4. Install right pedal supporter(18) with the same way.
STEP 8
1. Handle pulse connection
post(4),and attach the Handlebars(11) to Upright post(4),tighten with T-
shaped rotary knob(30).
2. Attach Console fixed piece(12) to the Upright post(4),tighten with
Philips C.K.S. full head screw(55).
Tip: Make sure all screws are in the hexagonal hole before tighten all the
bolts.
STEP 9
1. Connect the Console communication wire(32) and Console connection
wire(37),connect the Handle pulse connection wire(35) and Console
outset(36).
2. Attach the Console(13) to the Console fixed piece(12),tighten with
Philips C.K.S. full head screw(57).
3. Attach the Handlebar cover(L)(27)
through the Handlebars(11) to the Upright post(4),tighten with Philips
C.K.S. full head screw(56). Tip: Make sure all screws are in the hexagonal
hole before tighten all the bolts.
the computer. To achieve a satisfying result, intensity should be adjusted
during workout, by means of knob UP (+) and DOWN (-).Available
resistance levels: from 1 to 32. The load system is independent of speed.
