EN
NOTES Please keep this operation manual for future use. This exercise machine is intended for home use only.

SAFETY REMARKS

 Prior to the assembly of the device and training, read carefully this
instruction manual. Safe and effective use of the device can be
guaranteed only if it is assembled, maintained, and used appropriately,
in a manner described in the manual. If you are not the user, please
provide all the users with this instruction and inform them about all
possible hazards and precautions.
 Prior to starting with any exercises, please consult a doctor in order to
make sure that there are no mental or physical conditions that could be
harmful to your health and safety. The consultancy with a doctor may also
protect you against an inappropriate use of the device. A doctor will
specify whether taking drugs that would have an effect on pulse, pressure
or cholesterol level is justified.
 Pay attention to your body signals. Inappropriate or excessive training
may have a negative influence on your health. Immediately stop
exercising if any of the following symptoms occurs: pain, chest
constriction, irregular pulse, exceptional shortness of breath, faints,
vertigo, nausea. If any of the above symptoms occurs, contact your
doctor immediately and give up training until then.
 Children and animals should be kept away from the device. The device
is intended only and exclusively for adults.
 The device should be placed on a straight, stable and tough surface,
protected with a mat or a carpet. For the sake of safety, 2 m of free space,
needed for a safe usage, should be left to each side around the device.
Prior to starting any exercises, make sure that all the bolts and nuts are
tightly fitted. Please, pay special attention to the parts that are prone to
wearing out the most.
 An appropriate safety level of this device may by guaranteed only if it is
subject to regular service and inspection.

TECHNICAL SPECIFICATIONS

Net weight – 43 kg, Flywheel – 6 kg
Dimensions of the assembled exercise machine – 130 x 60 x 158 cm

LIST OF PARTS

Diagram – p. 37
NO. NAME
1 Main frame
2 Front stabilizer
3 Rear stabilizer
4 Upright post
7 Body arm set
8 Body arm(L)
9 Body arm(R)
10 Pedal supporter(L/R)
11 Handlebars
12 Console fixed piece
13 Console
14 Upright post cover
15 Bottle holder
Axle Φ15x311.5
16
17 Pedal(L)
18 Pedal(R)
Bushing Φ10.5x Φ14x10
21
22 Handlebar rotary knob
23 Body Arm cover 1(Upper)
www.spokey.pl
USER'S GUIDE
qty NO. NAME
1 37 Console connection wire
Allen C.K.S. half thread screw
1 38
M8x50x20
Spring washer Φ8
1 39
Flat washer Φ8.5x Φ20xt1.5
1 40
Curved washer Φ8.5xR25xt2.0
1 41
Allen C.K.S. half thread screw
1 42
M8x63x20
1 43 Hex self-locking nut M8
Allen C.K.S. full thread screw
1 44
M8x20
Philips C.K.S. self-tapping screw
1 45
ST4x16
Philips pan head full thread
1 46
screw M4x6
Wave spring washer Φ15
1 47
Allen C.K.S. half thread screw
1 48
M8x40x20
1 49 carriage screw M10x50x20
Flat washer Φ10
1 50
1 51 Hex locking nut M10
Allen C.K.S. hollow screw
1 52
Φ10x55-M6x20
Flat washer Φ6
1 53
Allen C.K.S. full thread screw
1 54
M6x15
Philips C.K.S. full head screw
2 55
M5x10
 The device should be always used in accordance with its purpose.
Should during the assembly or use any of the parts appear to be faulty
or make alarming sounds, stop using the exerciser and have it serviced .
You must not use a damaged device.
 During training, wear appropriate clothes. Avoid loose clothes that could
get caught in the device or such that could restrict or even make
movement impossible. It is also advised to exercise in appropriate sport
shoes. At the beginning, set a slow pace. During exercises, hold
handgrips and do not leave the saddle.
 The bicycle is intended for home use. Maximum allowed user's body
weight amounts to 120 kg.
 Take special precautions while lifting and moving the device. The device
should be always moved by two persons. While lifting or moving the
equipment, maintain an appropriate posture so as to avoid backbone
damage.
 The equipment was counted among class H and C and is intended for
home use exclusively. It cannot be used as a therapeutic or rehabilitation
equipment.
 While assembling the device, strictly follow the enclosed instruction and
use only the parts included in the set. Prior to the assembly, check
whether the set contains all the parts that the enclosed list includes.
 It is advised against leaving control devices, which could restrict
movement, in such a position that any of the elements sticks out.
Warning: prior to starting a training on this device, read the instruction
manual carefully.we do not hold responsibility for injuries or damages to
objects caused by an inappropriate use of this product. Body injuries may
happen due to an inappropriate or too intensive training.
Maximum weight of the user – 120 kg
The equipment is designed for full body exercise
qty NO.
1 69
4 70
10 71
12 72
5 73
2 74
11 75
10 76
24 77
4 78
4 79
4 80
4 81
4 82
5 83
2 84
2 85
7 86
4 87
5
NAME
Circlip shaft Φ10
Circlip shaft fixed piece
Circlip shaft fixed piece
Crank set
Disc cover
Dis Φ378.6x32
Belt pulle Φ263.7x22.2y
Crank axle Φ17x111.3
Circlip for shaft Φ17
Allen C.K.S. full thread screw 5/16-
18UNC-1"
Fixed magnet set
Philips C.K.S. self-tapping screw
ST4x12
Brake tension spring
Foam grip Φ30xt3.0x350
Pipe plug Φ32xt1.5
Deep groove ball bearing 6002-2RS 8
Deep groove ball bearing 6000-2RS 4
Motor cover(L)
Motor cover ®
www.spokey.eu
qty
1
1
1
2
2
2
1
1
2
2
1
1
1
2
2
1
1
