PARAMETER LIST

Time schedules are programmed by setting the individual
parameters encountered when scrolling with the arrow keys.
Warning: there are a total of 37 parameters, but not of all them
are accessible. Whether certain parameters will be displayed
or not depends on the value assigned to the first parameter
(H00), i.e. the operating mode selected. More specifically:
 if H00=1 (ON/OFF mode), parameters H18 to H29 will not
be displayed
 if H00=2 (operation based on temperature SETPOINT),
parameters H12 to H17 will not be displayed
 if H00=0, the time programming function is disabled and
therefore no parameter will be displayed except for H00
Below is a description of all 37 parameters, in sequence.
 H00 ENABLING AND OPERATING MODES
- H00=0 : scheduling disabled
- H00=1 : ON/OFF time schedules
- H00=2 : time schedules based on temperature SETPOINT
CLO:
- H01 = HOUR of controller clock
- H02 = MINUTES of controller clock
DAY:
- H03 = DAY OF THE WEEK
Hr1:
- H04 = HOUR (0-23) of SCHEDULE 1
- H05 = MINUTES (0-59) of SCHEDULE 1
Hr2:
- H06 = HOUR (0-23) of SCHEDULE 2
- H07 = MINUTES (0-59) of SCHEDULE 2
Hr3:
- H08 = HOUR (0-23) of SCHEDULE 3
- H09 = MINUTES (0-59) of SCHEDULE 3
Hr4:
- H10 = HOUR (0-23) of SCHEDULE 4
- H11 = MINUTES (0-59) of SCHEDULE 4
- H12 = STATUS (ON or OFF) of TIME SLOT 1
- H13 = STATUS (ON or OFF) of TIME SLOT 2
- H14 = STATUS (ON or OFF) of TIME SLOT 3
- H15 = STATUS (ON or OFF) of TIME SLOT 4
- H16 = STATUS (ON or OFF) of TIME SLOT 5
- H17 = STATUS (ON or OFF) of TIME SLOT 6
SP1:
- H18 = SUMMER temperature SETPOINT of TIME SLOT 1
SP2:
- H19 = SUMMER temperature SETPOINT of TIME SLOT 2
SP3:
- H20 = SUMMER temperature SETPOINT of TIME SLOT 3
SP4:
- H21 = SUMMER temperature SETPOINT of TIME SLOT 4
SP5:
- H22 = SUMMER temperature SETPOINT of TIME SLOT 5
SP6:
- H23 = SUMMER temperature SETPOINT of TIME SLOT 6
SP1:
- H24 = WINTER temperature SETPOINT of TIME SLOT 1
SP2:
- H25 = WINTER temperature SETPOINT of TIME SLOT 2
SP3:
- H26 = WINTER temperature SETPOINT of TIME SLOT 3
SP4:
- H27 = WINTER temperature SETPOINT of TIME SLOT 4
SP5:
- H28 = WINTER temperature SETPOINT of TIME SLOT 5
SP6:
- H29 = WINTER temperature SETPOINT of TIME SLOT 6
FWEC3
Advanced plus electronic controller
FC66002765
Mon:
- H30 = daily profile (1 or 2) for MONDAY
Tue:
- H31 = daily profile (1 or 2) for TUESDAY
Wed:
- H32 = daily profile (1 or 2) for WEDNESDAY
Thu:
- H33 = daily profile (1 or 2) for THURSDAY
Fri:
- H31 = daily profile (1 or 2) for FRIDAY
Sat:
- H35 = daily profile (1 or 2) for SATURDAY
Sun:
- H36 = daily profile (1 or 2) for SUNDAY
- H37 = 24H or 12H display
DEFAULT VALUES OF PARAMETERS
- H00 = 0 (scheduling disabled)
- H01 = 06:00
- H02 = 22:00
- H03 = 08:00
- H04 = 20:00
- H12 = OFF
- H13 = ON
- H14 = OFF
- H15 = OFF
- H16 = ON
- H17 = OFF
- H18-H23 = 25°C
- H24-H29 = 22°C
- H30-H34 = 1
- H35-H36 = 2
- H37 = 24H
If the 12H display mode has been set (parameter H37), for
configuration parameters H01 to H11 (except H03) the display
will not show the sequential number of the parameter but rather
the hourly situation expressed in AM/PM.
DISPLAY
If the time programming function is enabled, when the thermostat
is on the clock symbol will always appear and it will be possible
to check whether the time settings are correct (only for a few
instants) by simultaneously pressing the SEL+MODE buttons.
When the thermostat is off, the clock symbol and current hour
will appear constantly on the display only if the ON/OFF time
programming mode is enabled.
Installation and user manual
13
