CONFIGURATION OF DIGITAL OUTPUTS
(PARAMETERS P09,P10,P11,P12)
P09,P11
= 8
The contact is used to switch ON/OFF any external device
for humidifying the air (heating mode only). The ON/OFF
logic is based on a reading of the humidity in the room and
the SETPOINT selected with parameter P13. It follows the
diagram shown:
P09,P11
= 9
The status of the contact indicates whether the air temperature
is too high compared to the temperature SETPOINT (only in the
"summer" mode); the ON/OFF logic is thus tied to the value of
the temperature SETPOINT, according to the following step:
P09,P11
= 10
The status of the contact indicates whether the air temperature
is too low compared to the temperature SETPOINT (only in the
"winter" mode); the ON/OFF logic is thus tied to the value of the
temperature SETPOINT, according to the following step:
P09,P11
= 11
The digital output is not governed by the controller; the contact
is always open.
P09,P11
= 12
The contact status indicates that water temperature is low. The
activation/deactivation logic follows the step:
The two tables below provide a detailed explanation of the
meaning of the contact associated with each digital output:
Installation and user manual
6
P09
0
1 OPERATING MODE
UNIT IN COOLING OR
Air humidity
2
3
4 UNIT IN HEATING MODE
5
CONTROLLER STATUS
6
ALARM TRIGGERED
7
DEHUMIDIFICATION
Air temperature
8
HUMIDIFICATION CALL
9
10
11
12
Air temperature
P11
0
1 OPERATING MODE
UNIT IN COOLING OR
2
Water temperature
3
4 UNIT IN HEATING MODE
5 CONTROLLER STATUS
6 ALARM TRIGGERED
7
DEHUMIDIFICATION
8
HUMIDIFICATION CALL
9
10
11
12
DIGITAL 1 OUTPUT
P10 = 0
(NO CONTACT)
OPEN CLOSED
CONTACT CONTACT
NOT USED --
SUMMER WINTER
NO YES
HEATING MODE
UNIT IN COOLING
NO YES
MODE
NO YES
OFF ON
NO YES
EXTERNAL
NO YES
CALL
EXTERNAL
NO YES
HIGH ROOM
NO YES
TEMPERATURE
LOW ROOM
NO YES
TEMPERATURE
NOT USED --
LOW WATER
YES NO
TEMPERATURE
DIGITAL 2 OUTPUT
P12 = 0
(NO CONTACT)
OPEN CLOSED
CONTACT CONTACT
--
SUMMER WINTER
NO YES
HEATING MODE
UNIT IN COOLING
NO YES
MODE
NO YES
OFF ON
NO YES
EXTERNAL
NO YES
CALL
EXTERNAL
NO YES
HIGH ROOM
NO YES
TEMPERATURE
LOW ROOM
NO YES
TEMPERATURE
WATER CIRCUIT
ENABLED FOR YES NO
COOLING
WATER CIRCUIT
ENABLED FOR YES NO
HEATING
Advanced plus electronic controller
P10 = 1
(NC CONTACT)
OPEN CLOSED
CONTACT CONTACT
-- -- --
WINTER SUMMER
YES NO
YES NO
YES NO
ON OFF
YES NO
YES NO
YES NO
YES NO
YES NO
-- -- --
NO YES
P12 = 1
(NC CONTACT)
OPEN CLOSED
CONTACT CONTACT
-- -- --
WINTER SUMMER
YES NO
YES NO
YES NO
ON OFF
YES NO
YES NO
YES NO
YES NO
YES NO
NO YES
NO YES
