Replacing Wheels; Storing The Product - Ryobi RLM4614 Übersetzung Der Originalanleitung

rubbing alcohol may be used to remove any stubborn
dirt.
CAUTION: Do not lubricate any of the wheel components
Lubrication may cause the wheel components to fail during
use, which could result in mower damage.
■ Reinstall wheel gear with the arrows facing the front
of the mower. Reinstall pins, washer, e-ring, and dust
cover.
■ Reinstall wheel and nut. Tighten nut to secure.

REPLACING WHEELS

See figure 14.
WARNING
Only use replacement wheels approved by the
manufacturer of your mower, use wheels not approved
by the manufacturer of your mower is hazardous and
could result in serious person injury.
■ Stop the engine and disconnect the spark plug wire.
Allow the blade to come to a complete stop.
■ Remove the nut from the wheel axle, then remove the
wheel.
■ Replace with new wheel and reinstall nut to secure.

STORING THE PRODUCT

When storing the mower for 30 days or more:
■ If using fuel stabilizer, follow stabilizer manufacturer's
directions to add stabilizer to petrol in fuel tank. Run
engine at least 10 minutes after adding stabilizer to
allow the stabilizer to reach the carburetor.
WARNING
Do not store the lawn mower with petrol in the tank
inside a building where fumes may reach an open fl ame
or spark.
■ If not using fuel stabilizer, allow the engine to run until
the mower is completely out of petrol.
■ Once the engine has stopped, allow the blade to come
to a complete stop and disconnect the spark plug wire.
■ Turn the fuel valve to the closed position.
■ Turn mower on its side (with carburetor facing up) and
clean grass clippings that have accumulated on the
underside of the mower deck.
■ Clean the underside of the mower deck.
■ Wipe the mower clean with a dry cloth.
■ Check all nuts, bolts, knobs, screws, fasteners, etc., for
tightness.
■ Inspect moving parts for damage, breakage, and wear.
Have repairs made on any damaged or missing parts.
■ Store the mower in a well-ventilated area that is clean,
dry, and out of the reach of children.
■ Do not store near corrosive materials such as fertilizer
or rock salt.
To lower the handle before storing
See figure 15.
■ Loosen the starter rope guide knob. Remove starter
rope from guide and allow to retract into engine.
■ Fully loosen the handle knobs on the sides of the
handle and fold the upper handle down.
■ Push inward on each side of the lower handle, and
lift the sides of the lower handle past the edges of the
handle mounting brackets.
■ Fold the lower handle forward, making sure not to bend
or kink the control cables.
TRANSPORTATION
■ Stop the product, disconnect the spark plug wire and
wait until the blade comes to a complete stop, and allow
it to cool.
■ Empty the fuel tank by running the engine till it stops.
Empty oil by following instruction for changing oil.
■ Secure the product against movement or falling to
prevent injury to persons or damage to the product.
