ATTRIBUT-ID ZUGRIFFSREGEL
1 GET
2 GET
3 GET
4 GET
5 GET
6 GET
7 GET
8 GET
9 GET / SET
12 GET / SET
13 GET
14 GET
15 GET
16 GET
17 GET
ATTRIBUTE VON DEVICENET- CONNECTION-KLASSE
BENENNUNG
INSTANZ 3 - BIT-STROBE
STATE
INSTANCE TYPE
TRANSPORT CLASS
TRIGGER
PRODUCED
CONNECTION ID
CONSUMED
CONNECTION ID
INITIAL COMM.
CHARACTERISTICS
PRODUCED
CONNECTION SIZE
CONSUMED
CONNECTION SIZE
EXPECTED PACKET RATE
WATCHDOG ACTION
PRODUCED CONN.
PATH LENGTH
PRODUCED
CONNECTION PATH
CONSUMED CONN.
PATH LENGTH
CONSUMED
CONNECTION PATH
INHIBIT TIME
37
Referenz
DATENTYP WERT
USINT 0 = Nicht existent
1 = Konfiguration
3 = Hergestellt
4 = Zeitsperre
USINT 1 = I/O Verbindung
USINT 0x82
UINT
UINT
USINT 0x02
UINT 0 bis 8
UINT 8
UINT Timer-Resolution 2 ms
UINT 0 = Zeitsperre
1 = Autom. löschen
2 = Autom. rückstellen
UINT 3
0x63 (Hex String)
Hex-String - Versammlung #
UINT 3
0x63 (Hex String)
Hex-String - Versammlung #
USINT 0
