You can connect a Yamaha Bluetooth wireless audio receiver (such as YBA-10, sold separately) to the DOCK terminal of
this unit and enjoy the music contents stored in your Bluetooth component (such as a portable music player) without
wiring between this unit and the Bluetooth component.
Notes
• This unit supports A2DP (Advanced Audio Distribution Profile) of the Bluetooth profile.
• For a complete list of status messages that appear on the front panel display and GUI screen, see "Bluetooth™" (page 71).
About "Pairing"
Pairing (registration of the Bluetooth devices) must be performed when making Bluetooth connections between the
Yamaha Bluetooth wireless audio receiver and your Bluetooth components for the first time. Once pairing is complete,
you can select one of the Bluetooth components to connect to the Yamaha Bluetooth wireless audio receiver for playback.
y
• Yamaha Bluetooth wireless audio receiver YBA-10 can be paired with up to eight Bluetooth components. If ninth pairing data is registered, the pairing
data for the component least recently used is cleared.
Pairing the Bluetooth™ wireless audio
receiver and your Bluetooth
component
y
• If the pairing data has been cleared from the Bluetooth wireless audio
receiver or your Bluetooth component, you need to perform pairing
again.
• For details on operations on your Bluetooth component, refer to the
operating instruction of it.
To ensure security, a time limit of 8 minutes is set for
the pairing operation. You are recommended to read
and fully understand all the instructions before starting.
1
Rotate the TINPUT selector (or press
dDOCK) to select "BLUETOOTH" (DOCK)
as the input source.
2
Turn on the Bluetooth component you want
to pair with and set it to pairing mode.
3
Press sOPTION on the remote control.
The Option menu for "BLUETOOTH" is displayed
(page 43).
Option Menu
Volume Trim
Connect
Pairing
BLUETOOTH
Input
7ch Enhancer
DSP
4
Press jCursor n to select "Pairing" and
then press jENTER.
"Searching" appears and the pairing operation starts.
y
• To cancel pairing, press jRETURN.
• You can also start pairing operation by holding down
GMEMORY on the front panel.
Using Bluetooth™ components
5
Make sure the Bluetooth component
recognizes the Bluetooth wireless audio
receiver.
If the Bluetooth component detects the Bluetooth
wireless audio receiver, "YBA-10 YAMAHA"
(example) appears in the Bluetooth device list.
6
Select the Bluetooth wireless audio receiver
in the Bluetooth device list, and enter a pass
key "0000" into the Bluetooth component.
When pairing is complete, "Completed" appears on
the front panel display.
Playback of the Bluetooth™
component
1
Rotate the TINPUT selector (or press
dDOCK) to select "BLUETOOTH" (DOCK)
as the input source.
2
Press sOPTION on the remote control.
3
Press jCursor n to select "Connect" and
then press jENTER.
The Bluetooth connection is established between the
Bluetooth wireless audio receiver and your Bluetooth
component connected last time.
y
• If the Bluetooth wireless audio receiver cannot find the Bluetooth
component connected last time, "Not found" appears on the front
panel display.
• To disconnect the Bluetooth wireless audio receiver from the
Bluetooth component currently connected, select "Disconnect" and
then press jENTER or perform a disconnect operation on the
Bluetooth component.
• To make a connection between the Bluetooth wireless audio receiver
and another Bluetooth component (already paired), perform a
connect operation on the Bluetooth component while no Bluetooth
connection is established on the Bluetooth wireless audio receiver.
4
Start playback of the Bluetooth component.
5
To exit the Option menu, press sOPTION.
