Operating various settings for this unit (Setup menu)
y
• When "Surround Back Speaker" is set to "None", "PLIIx Movie",
"PLIIx Music" and "PLIIx Game" of the surround decode mode
(page 29) are not available.
Bass Crossover Frequency
Choices: 40Hz, 60Hz, 80Hz*, 90Hz, 100Hz, 110Hz, 120Hz,
160Hz, 200Hz
Sets the lower limit of the low-frequency component
output from a speaker with a size set to "Small" (Small x
1, Small x 2) Sound with a frequency below that limit is
output from a subwoofer or front speakers.
If your subwoofer has a volume control or a crossover
frequency control, set the volume to half or the crossover
frequency at the maximum.
Subwoofer Phase
Choices: Normal*, Reverse
Sets the phase of your subwoofer if bass sounds are
lacking or unclear.
Normal Select this not to change the phase of your
subwoofer.
Reverse Select this to reverse the phase of your
subwoofer.
■
Speaker Level
Adjustable range: –10.0dB to +10.0dB (0.5dB step)
Defaults:
0dB (FR.L, FR.R, SWFR, PR.L, PR.R)
–1.0dB (CNTR, SUR.L, SUR.R, SBL, SBR)
Separately adjusts volume of each speaker so that the
sounds form speakers are at the same volume at the
listening position. Items to be displayed vary depending
on the number of speakers connected.
y
• When only one surround back speaker is connected, "SB" appears
instead of "SBL" and "SBR".
• You can adjust the volume listening to test tones when you set "Test
Tone" to "On" (on this page).
• If your subwoofer has a volume control or a crossover frequency control,
set the volume to half or the crossover frequency at the maximum.
■
Speaker Distance
Adjusts timing at which each speaker outputs sound so
that sounds from speakers reach the listening position at
the same time. Set unit (Unit) first and set the distance of
each speaker.
Unit
Choices: meters (m)*, feet (ft)
meters (m) Displays the speaker distance in meters.
feet (ft) Displays the speaker distance in feet.
50
En
FR.L / FR.R / CNTR / SUR.L / SUR.R / SBL / SBR /
SWFR / PR.L / PR.R
Adjustable range: 0.30m to 24.00m (1.0ft to 80.0ft)
Defaults: 3.00m (10.0ft) (FR.L, FR.R, SWFR, PR.L,
PR.R)
2.60m (8.5ft) (CNTR)
2.40m (8.0ft) (SUR.L, SUR.R, SBL, SBR)
y
• Available items differ depending on the "Speaker Configuration" settings
(page 48).
• When only one surround back speaker is connected, "SB" appears
instead of "SBL" and "SBR".
■
Equalizer
Adjusts sound quality and tone using a parametric graphic
equalizer.
EQ Type Select
Choices: Auto PEQ, GEQ*, Off
Selects an equalizer type.
Auto PEQ Uses a parametric equalizer selected in
"Auto Setup". Characteristics of the
currently used parametric equalizer are
displayed below "Auto PEQ".
Uses a graphic equalizer. Press jENTER
GEQ
to adjust the characteristics of the graphic
equalizer.
Off Not use a graphic equalizer.
GEQ
Channels Front Left, Front Right, Center, Surround Left,
Surround Right, Surround Back Left, Surround
Back Right
Choices: 63Hz, 160Hz, 400Hz, 1kHz, 2.5kHz, 6.3kHz,
16kHz
Adjustable range: –6.0dB to 0dB* to +6.0dB (0.5dB step)
Adjusts sound quality of each speaker using a graphic
equalizer. The graphic equalizer of this unit can adjust
signal levels in 7 frequency ranges.
To adjust the signal level within each range, press
jCursor l / h to select the desired speaker while
"Channel" is selected, press jCursor k / n to select the
desired frequency band and then press jCursor l / h
to adjust the signal level.
■
Test Tone
Choices: Off*, On
Switches between on and off of an oscillator that generates
test tones. When "On" is selected, you can adjust the
settings of "Manual Setup" while listening to a test tone.
Off Not generate test tones.
On Generates test tones.
