Zeroing
To zero your riflescope, you need to set a zeroing distance first in the range of 1 to 910 m (995
yards).
• Press and hold the controller button (6) to enter the main menu.
•
Add new
Rotate the controller ring to select menu item
controller button.
distance
•
Press the controller button (6) briefly to enter the Add New Distance submenu.
•
Rotate the controller ring to select a value for each distance category. Press the controller
button (6) briefly to switch between digits.
•
Having set the desired distance, press and hold the controller button to save it.
•
The distance you set first becomes a primary distance – shown with icon
the distance value.
Note: Maximum number of zeroing distances for each profile is ten.
Operating the
Press and hold the controller button (6) to enter the main menu.
distances
•
Rotate the controller ring (6) to select the Zeroing menu item
pressing the controller button (6) – the zeroed distances are displayed.
•
The values (e.g., +7.0) shown on the right of the distance values stands for the number of
clicks along the Y axis that the reticle position at other distances differs from the reticle
position of the primary distance.
Zeroing • To zero at any distance again, rotate the controller ring (6) to select the required distance
Parameters and briefly press the controller button (6).
Settings
• Enter the Zeroing submenu by briefly pressing the controller button (6)
•
The zeroing screen, allowing changes of zeroing coordinates, will appear.
Windage/
The Windage/Elevation additional menu item allows you to adjust the reticle position. For a
Elevation
detailed description of reticle adjustments, refer to the Zeroing section.
Correction
Magnification
Magnification allows you to magnify the digital zoom of the riflescope when zeroing, reducing
the minute of angle click. It improves the zeroing accuracy.
•
Rotate the controller ring (6) to select the Magnification submenu item and enter by briefly
pressing the controller button.
•
Rotate the controller ring (6) to select a digital magnification value of the riflescope (e.g.,
x4).
•
Press the controller button (6) briefly to confirm your selection.
The minute of angle click when using the Zoom In function is indicated in the table of
technical specifications.
Zeroing with The feature of the function is that there is no need to constantly keep the riflescope at the
FREEZE Function
point of aiming.
•
Rotate the controller ring (6) to move the cursor to the Freeze function.
•
Align the reticle with the point of aiming and press the controller (6) or ON (3) button. A
screenshot will be taken, an icon
•
Go to the additional Windage/Elevation submenu and adjust the position of the reticle (see
the Zeroing section).
•
Select the Freeze submenu item again and briefly press the controller (6) or ON (3) button -
the image will "unfreeze".
USER MANUAL FOR DIGEX NIGHT VISION DIGITAL RIFLESCOPE
and enter by briefly pressing the
on the right of
and enter by briefly
will appear.
•
Name Distance Rotate the controller ring (6) to select the Name Distance submenu item and enter it by
briefly pressing the controller button.
•
Rotate the controller ring (6) to select a value for each digit. Press the controller button (6)
briefly to switch between digits.
•
Press and hold the controller button (6) to confirm the selection.
•
Change Primary Select a Non-primary Distance and enter the submenu for operating the distances with a
Distance brief press of the controller button (6).
•
Select item Change Primary Distance.
• Press the controller button (6) briefly.
Icon next to the selected distance confirms the change of primary distance.
The differences of other distances from a new standard distance along the Y axis are
recalculated as per clicks.
•
Delete Distance ВSelect the distance you wish to delete and enter the submenu for operating the distances
with a brief press of the controller button.
•
Select Delete Distance item.
•
Select Yes in the dialog box that appears to delete a distance. No – to cancel deletion.
Attention! If the primary distance is deleted, the first distance on the list automatically
becomes the new primary distance.
Wi-Fi Activation • Press and hold the controller button (6) to enter the main menu.
•
Rotate the controller ring (6) to select the Wi-Fi Activation menu item.
• To turn Wi-Fi On, briefly press the controller button (6).
•
To turn Wi-Fi Off, briefly press the controller button (6).
Wi-Fi Settings
This item enables you to set up your riflescope for operation in a Wi-Fi network.
This item enables you to set a password to access the riflescope from an external device. The
password is used to connect an external device (i.e. smartphone) to the riflescope.
•
Password Setup Press the controller button (6) to enter the Password Setup submenu.
•
The default password (12345678) will appear on the screen.
•
Rotate the controller ring (6) to set the desired password. Press the controller button (6) to
toggle through the digits.
•
Press and hold the controller button (6) to save the password and exit from the submenu.
Access Level
This sub-function allows you to configure the appropriate level of access to your device made
Setup
available to the Stream Vision application.
Owner Level. A Stream Vision user has full access to all the device's functions.
Guest Level. A Stream Vision user can only view video footage from the device in real time.
• Press and hold the controller button (6) to enter the main menu.
•
Press the controller button (6) briefly to enter the submenu.
• Rotate the controller ring (6) to select the access level.
•
Press and hold the controller button (6) to confirm your selection and exit from the
submenu.
General Settings This menu item allows you to configure the following settings:
• Press the controller button (6) briefly to enter the Language submenu .
•
Rotate the controller ring (6) to select one of the available interface languages: English,
Language
German, Spanish, French, Italian or Russian.
Settings
•
Confirm your selection with a short press of the controller button (6).
• Press and hold the controller button (6) to save your selection and exit from the submenu.
