the second tab comes next.
•
Press the controller button (6) briefly to open subitems of the main menu.
• Press and hold the controller button (6) to exit from a subitem of the main menu.
•
Automatic exit from the main menu occurs after 10 seconds of inactivity.
•
After exiting the main menu the cursor location (
riflescope is turned off). When restarting the riflescope and entering the menu the cursor will be on the first
menu item.
•
GENERAL VIEW OF MENU
Tab 1
MAIN MENU CONTENTS AND DESCRIPTION
Zeroing Profile
This main menu item allows you to select one of five profiles (А, В, С, D, E) to use. Each profile
includes the following parameters:
•
A set of zeroed distances
•
Reticle color
•
Reticle type
Different profiles can be used when using the riflescope on different weapons or when
shooting with different ammunition.
•
Press and hold the controller button (6) to enter the main menu.
•
Rotate the controller ring (6) to select the Zeroing Profile menu item.
• Press the controller button (6) briefly to enter the Zeroing Profile submenu.
•
Rotate the controller ring (6) to select one of the zeroing profiles (marked with the letters
A, B, C, D, E).
•
Confirm your selection with a short press of the controller button (6).
•
The name of the selected profile appears in the status bar at the bottom of the display.
USER MANUAL FOR DIGEX NIGHT VISION DIGITAL RIFLESCOPE
) is stored only for a single working session (i.e. until the
Tab 2
Icon Brightness Adjust the brightness level of the icons and screensavers (Pulsar, Display off) on the display.
• Press and hold the controller button (6) to enter the main menu.
•
Rotate the controller ring (6) to select the Icon Brightness menu item.
•
Press the controller button (6) briefly to enter the Icon Brightness submenu.
• Rotate the controller ring (6) to set the desired brightness level (1 to 10).
•
Press the controller button (6) briefly to confirm the selection.
Reticle Setup
This main menu item allows you to select the reticle shape, color and brightness.
• Press and hold the controller button (6) to enter the main menu.
•
Rotate the controller ring (6) to select the Reticle Setup menu item.
•
Press the controller button (6) briefly to enter the Reticle Setup submenu.
Reticle Type Selection of the aiming reticle shape.
• Rotate the controller ring (6) to select the Reticle Type submenu.
•
Press the controller button (6) briefly to enter the Reticle Type submenu.
• Rotate the controller ring (6) to select the desired aiming reticle shape from the list that
appears. The reticle type changes as the cursor goes down the reticle list.
• Press the controller button (6) briefly to confirm the selection.
Reticle Color •
Selection of reticle color.
•
Rotate the controller ring (6) to select the Reticle Color submenu.
•
Press the controller button (6) briefly to enter the Reticle Color submenu.
• Rotate the controller ring (6) to select one of the color options for the reticle:
– Black/Red
– White/Red
– Black/Green
– White/Green
– Red
– Green
– Yellow
– Blue
– Orange
• Press the controller button (6) briefly to confirm the selection.
Reticle
Adjust the brightness level of the aiming reticle.
Brightness
•
Rotate the controller ring (6) to select the Reticle Brightness submenu.
•
Press the controller button (6) briefly to enter the Reticle Brightness submenu.
• Rotate the controller ring (6) to set the desired brightness level (1 to 10).
•
Press the controller button (6) briefly to confirm the selection.
