Do not use the charger if it has been modified or damaged.
•
The battery should be charged at an air temperature of 0 °C - + 45 °C or the lifespan of the battery will
decrease significantly.
•
Do not leave the charger with the battery connected to the mains for more than 24 hours after it has been
completely charged.
•
Do not expose the battery to high temperatures or naked flames.
•
Do not submerge the battery.
•
Do not connect an external device with a current consumption that exceeds permitted levels.
•
The battery has short-circuit protection. However, all situations that may cause short-circuiting should be
avoided.
•
Do not disassemble or deform the battery.
•
Do not drop or strike the battery.
•
When using the battery at low temperatures, the battery capacity decreases, this is normal and not a defect.
•
Do not use the battery at the temperatures above those shown in the table, this may decrease battery life.
•
Keep the battery out of the reach of children.
SWITCHING AND CHANGING THE BATTERIES
Digex riflescopes are powered by 2 batteries: a built-in APS3 battery pack and a removable APS2 or APS3 battery
pack.
•
If there are two batteries in the device, two battery icons are displayed in the status
bar (1 - built-in battery, 2 - removable battery). The battery from which the device is
powered is displayed in blue, with the inactive battery displayed in grey.
•
If there is no removable battery in the device, only one blue icon for the internal battery is displayed in the
status bar.
•
When both batteries are fully charged, the device is powered by the removable battery. If the removable
battery level is low, the device will switch to the built-in battery.
•
When charging the batteries using the MicroUSB port (10), the built-in battery is charged first. When the built-
in battery charge level reaches 100%, the device switches to charging the removable battery. The battery level
is displayed in percentages above the icons in the status bar.
•
It is possible to replace the removable battery with the device turned off or if turned on when being powered
by the built-in battery (the device will continue to work properly).
Attention! When removing the removable battery from the device powered by it, the device will reboot and
switch to operation from the built-in battery. The device will automatically switch to the removable battery if it
has sufficient charge after installation.

EXTERNAL POWER SUPPLY

•
Power can be supplied from an external source, such as a power bank (5V).
•
Connect the external power supply to the MicroUSB port (10) of the riflescope.
•
The riflescope switches to the external power source, while the built-in APS3 battery pack and the removable
APS2/APS3* battery pack will gradually recharge.
•
A rechargeable battery icon indicating the percentage of battery life will appear in the status bar.
•
When you turn off the external power source, the riflescope switches over to the removable battery without
turning off. When there is no removable battery or it has a low power level the device switches to the built-in
battery.
*Optional.
USER MANUAL FOR DIGEX NIGHT VISION DIGITAL RIFLESCOPE

OPERATION

Attention! It is forbidden to point the riflescope lens at intensive energy sources, such as laser radiation
emitting devices or the sun. It can damage the riflescopes electronic components. Warranty does not cover
damage arising from failure to comply with the operating rules.
MOUNTING ON THE WEAPON
To ensure accurate shooting the Digex riflescope should be properly mounted on the weapon.
•
The riflescope is fixed using mounts purchased separately. Use only high-quality mounts and rings that
are designed especially for your weapon. Follow the mounting manufacturer's recommendations on the
installation procedure and use the correct tools.
•
When mounting the riflescope, adjust its position to enable the correct and comfortable holding of the
weapon while maintaining the eye relief (the distance between the riflescope and eye) specified by the
technical specifications (see the table for technical specifications). Failure to comply may result in injury to
the shooter caused by the riflescope eyepiece when shooting.
•
It is recommended to install the riflescope as low as possible. However, it should not be in contact with the
barrel or receiver.
•
In order to avoid pinching the riflescope body, a tightening torque for the screws of the mounting rings must
not exceed 2.5Nm. A torque wrench is recommended to control the tightening torque.
•
Before using the riflescope for hunting, follow the instructions in the Zeroing section.
•
It is recommended to use an eyecup while using the riflescope in the dark in reduce light spillage from the
eyepiece. Mounting the eyecup on the riflescope eyepiece is enabled using built-in magnets.
IR ILLUMINATOR
The riflescope is equipped with a built-in IR illuminator featuring a wavelength of 940nm or 850nm, which
provides a significant increase in observation ranges in lowlight conditions and darkness.
INSTALLING BATTERY PACK IN THE IR ILLUMINATOR
The IR illuminator for the Digex riflescope is powered by an APS2 battery pack.
• To install the battery in the IR illuminator, turn the battery cover (21) counterclockwise and remove it.
•
Install the battery into the battery compartment (20) using the special guides in the IR illuminator body
designed for it.
•
When properly installed, the battery is fixed in the battery compartment (20).
•
Close the battery compartment (19), turning the cover
clockwise.
INSTALLING THE IR ILLUMINATOR
ON RIFLESCOPE
•
Open the mount ring of the IR illuminator (24).
•
Put the mount on the riflescope body so that the
mount half rings encircle the riflescope body.
•
Raising the eccentric lever (26), move it to the left.
Align the eccentric axis with the groove of the moving
half ring. The eccentric lever (26) shall take its seat.
•
Lock the eccentric lever (26) position by lowering it
down.
•
The IR illuminator mount should be as close as
possible to body of the riflescope lens.
•
Tighten the screw in the eccentric pin (25) using an
Allen wrench.
•
If the lever loosens during operation, tighten the
screw with an Allen key.
6
