Date Setting Press the controller button (6) briefly to enter the Date submenu. The date is displayed in
dd/mm/yyyy format.
•
Rotate the controller ring (6) to select the desired year, month and date. Press the controller
button (6) briefly to switch between digits.
•
Press and hold the controller button (6) to save your selected date and exit from the
submenu.
Time Setting • Press the controller button (6) briefly to enter the Time submenu.
•
Rotate the controller ring (6) to select the time format - 24 or AM/PM.
• Press the controller button (6) to proceed to the hour setting.
•
Rotate the controller ring (6) to select the hour value.
•
Press the controller button (6) to proceed to the minute setting.
• Rotate the controller ring (6) to select the minutes value.
•
Press and hold the controller button (6) to save your selected time and exit from the
submenu.
Units of Measure • Press the controller button (6) briefly to enter the Units of Measure submenu.
Selection
•
Rotate the controller ring (6) to select the unit of measurement - meters or yards, press the
controller button (6).
•
Return to submenu will happen automatically.
•
Default Settings Press the controller button (6) briefly to enter the Default Setting submenu .
•
Rotate the controller ring (6) to select Yes for factory reset or No to cancel the action.
• Confirm your selection with a short press of the controller button (6).
•
If Yes is selected, display will show "Return default settings?" and Yes and No options.
Select Yes to factory reset.
•
If No option is selected: restore default settings is canceled and it will return to the
submenu.
•
The following settings will be returned to their defaults before being changed by the user:
Operating Mode – Video
Interface language – English
Wi-Fi – Off (default password)
Magnification – initial value
PiP – Off
Unit of Measurement - Metric
Weapon Incline – Off
Weapon Profile – A
Reticle selection from the riflescope's memory – 1
Attention! After factory reset the date and time as well as the zeroing profiles data entered
by the user is saved.
•
Formatting the Press the controller button (6) briefly to enter the Format submenu .
Device's Memory
• Rotate the controller ring (6) to select Yes to format the device's memory card, or No to
Card
cancel the action.
• Confirm your selection with a short press of the controller button (6).
•
If Yes is selected, display will show Return default settings? and Yes and No options. Select
Yes to format the memory card.
If No is selected, formatting is cancelled and it will return to the submenu.
USER MANUAL FOR DIGEX NIGHT VISION DIGITAL RIFLESCOPE
Turning On/Off
This item allows you to enable (or disable) the microphone for recording sound during video
Microphone
recording.
•
Press and hold the controller button (6) to enter the main menu.
• Rotate the controller ring (6) to select the Microphone menu item.
•
To turn On the microphone, briefly press the controller button (6).
•
To turn Off the microphone, briefly press the controller button (6).
Accelerometer This menu item includes two subitems - Auto Shutdown and Side Incline.
Auto Shutdown This item allows you to activate the auto power off function for when the riflescope is in a
non-operating position (tilt up/down angle exceeding 70°, tilt right/left angle exceeding 30°).
•
Press and hold the controller button (6) to enter the main menu.
• Rotate the controller ring (6) to select the Accelerometer submenu, confirm the selection by
briefly pressing the controller (6).
• Rotate the controller ring (6) to select Auto Shutdown.
•
Press the controller button (6) briefly to enter the submenu.
•
Rotate the controller ring (6) to select the time period (1 min, 3 min, 5 min) after which the
riflescope will automatically shut down, or select "Switch Off" if you wish to deactivate Auto
Shutdown.
•
Confirm your selection with a short press of the controller button (6).
Note: If the auto power off function is activated, the status bar shows an icon and the
selected shutdown time period as
Side Incline
This item allows you to turn on/off the cant (horizontal/side incline) indicator. The incline is
indicated by two arrows on the right and left of the aiming reticle. Arrows show the direction
in which you should move your rifle to eliminate the cant.
There are three measures of incline:
5°-10 ° – one sector arrow;
10°-20 ° - two sector arrow;
Over 20° - three sector arrow (see figure).
A side incline of less than 5° is not displayed.
• Press and hold the controller button (6) to enter the main menu.
•
Rotate the controller ring to select the Accelerometer menu item.
•
Press the controller button (6) briefly to enter the Accelerometer submenu.
•
Rotate the controller ring to select Side Incline
•
Press the controller button (6) briefly to enter the Side Incline submenu.
•
Rotate controller ring to select On to turn on the cant indication or Off to turn it off.
• Confirm your selection with a short press of the controller button (6).
1 min.
10
