POWERING ON AND ADJUSTING THE IR ILLUMINATOR
Use the IR illuminator to improve the quality of observation in lowlight conditions at night.
• Turn on the IR illuminator by pressing the button (22) on the side of the light housing.
• Turn the knob (27) of the IR illuminator to control the illuminator power.
•
To adjust the IR light position in the riflescopes field of view, loosen the ring (19) of the IR illuminator by
turning it in the direction of the arrow.
•
Adjust the IR illuminator lens using its hinge system to align the IR illumination in the riflescopes field of
view. Once adjusted, tighten the IR illuminator ring (19).
•
Press the IR button (22) to turn off the IR illuminator.
The illuminator is equipped with an LED indicator (23) making it possible to monitor the battery level.
Indication modes are in the table below:
IR Operating Mode
The light is on, power supply 3.2-4.2V
The light is on, power supply less than 3.2V. Approximate operating time before the IR
illuminator turns off is 30 minutes
Light off
POWERING ON AND IMAGE SETTING
•
Open the lens cap (12).
• Press the ON button (3) briefly to power the riflescope on.
•
Adjust the resolution of the symbols on the display by rotating the diopter adjustment ring of the eyepiece
(2).
•
Rotate the lens focus ring (11) to focus on the object being observed.
•
Adjust the brightness, contrast of the display using the controller (6) (for more details, see the Quick Access
Menu Functions section).
•
After use, turn off the riflescope by long pressing the ON button (3).
ZEROING
The riflescope features two zeroing methods – one shot zeroing and using Freeze function. Zeroing is
recommended to be done at the temperature close to the riflescope operating temperature.
•
Mount the weapon with the riflescope installed on a bench rest.
•
Set a target at a certain distance.
•
Adjust the riflescope according to the recommendations in Powering On and Image Setting section.
•
Select the zeroing profile (see Zeroing Profile
•
Point the weapon at the center of the target and shoot.
•
If the impact point does not match the aiming point (center of the riflescope's reticle), press and hold down
the controller button (6) to enter the main menu.
•
Rotate the controller ring (6) to select the Zeroing submenu
controller button (6).
•
Set the zeroing distance value (see Zeroing menu item =>Add New Distance submenu
• Confirm the selected zeroing distance value by long pressing the controller button (6).
•
The Zeroing Parameters Settings additional menu will appear on the screen.
•
Cross hairs appear in the center of the display
right corner.
USER MANUAL FOR DIGEX NIGHT VISION DIGITAL RIFLESCOPE
Indicator color
–
main menu item)
. To confirm the selection, briefly press the
).
. The X and Y coordinates of the cross hairs are in the upper
• Rotate the controller ring (6) to select the icon
• Holding the reticle on the point of aim, rotate the controller ring (6) to move the cross hairs until the cross
hairs match the point of impact. To switch direction, briefly press the controller button (6).
Attention! To avoid holding the reticle on the point of aim, you can use the Freeze function – freezing the
zeroing screen (refer to Zeroing menu item =>Distance submenu =>Zeroing Parameters Settings=>Freeze
submenu ).
•
Press the controller button (6) briefly to switch the cross hairs movement direction from horizontal to vertical.
•
To save the new reticle position, press and hold the controller button (6). The reticle is aligned with the point
of impact and the submenu exits.
• Press and hold the controller button (6) again to exit the zeroing settings menu - the message "Zeroing
coordinates saved" appears, confirming the successful operation.
•
Fire a second shot - now the point of impact and the aiming point must be matched.
SMART RETICLE FUNCTION
*
When changing the digital magnification of the riflescope, the reticle that appears on the display is scaled, i.e. it
will change (increase or decrease) its form proportionally to the magnification, allowing the use of rangefinder
reticles at any digital magnification.
*Only for scalable reticles X51Fi-300, M56Fi, M57Fi
DISCRETE DIGITAL ZOOM
•
The riflescope functionality allows you to quickly magnify 2 and 4 times the standard magnification, as well as
return back.
•
Successively press the ZOOM (5) button to change the riflescope magnification.
•
While the icon is visible on the screen, rotate the controller ring (6) for smooth digital zooming of the
specified magnification.
QUICK ACCESS MENU FUNCTIONS
The basic settings (adjusting brightness and contrast, smooth digital zoom function, stadiametric rangefinder,
current profile and distance information) can be changed using the quick access menu.
•
Press the controller button (6) briefly to enter the quick menu.
• A short press of the controller button (6) enables you to switch between functions, as described below.
•
– rotate the controller ring (6) to change the display brightness value from 00 to 20.
Brightness
• – rotate the controller ring (6) to change the image contrast value from 00 to 20.
Contrast
•
- information on the current profile and zeroing distance in this profile (e.g., profile A, zeroing
distance of 100 m). This information is always displayed in the status bar. Rotate the controller ring (6) to
switch between the zeroing distances in the adjusted profile. This function is available if there are two or
more distances in the profile.
•
– rotating the controller ring (6), change the distance between the special
Stadiametric Rangefinder
mark points to determine the distance to the observed object (for more details on the rangefinder, see the
Stadiametric Rangefinder section).
•
Press and hold the controller button (6) to exit the menu or wait 10 seconds to exit automatically.
MAIN MENU FUNCTIONS
• Enter the main menu with a long press of the controller button (6).
•
To move through the main menu items, rotate the controller ring (6).
•
Main menu navigation is cyclical: when the last menu item of the first tab is reached, the first menu item of
. Press the controller button (6) briefly.
