Device Press and hold the controller button (6) to enter the main menu.
Information
• Rotate the controller ring (6) to select the Device Information menu item.
•
Press the controller button (6) briefly to enter the Device Information submenu.
This item allows the user to view the following information about the riflescope:
Full name of the riflescope.
SKU number.
Serial number of the riflescope.
Riflescope software version.
Hardware version.
Service information.
Battery information.

STATUS BAR

The status bar is at the bottom of the display and shows information on the actual operating status of the
riflescope, including:
•
Actual zeroing profile (e.g., A).
•
Zeroing distance (e.g., 100 m).
•
SumLight (on/off).
•
Current compound magnification.
•
Microphone (on or off).
•
Wi-Fi connection.
•
Auto power off function (e.g., 5 minutes).
•
Clock.
•
Battery discharge level (when riflescope is powered by a built-in or removable battery), or
•
External battery power indicator (if the riflescope is powered by an external power supply), or
•
Battery indicator with current percentage of charge (when charging from an external power source).
VIDEO RECORDING AND PHOTOGRAPHY
The riflescope is equipped with a video recording (photography) function where the observed image is saved
on the built-in memory card.
Before using the photo and video functions, read the Date Setting and Time Setting subsections of the Main
Menu Functions section of this manual.
Built-in recorder operates in two modes:
Photo (photography; the icon
is displayed in the upper left corner of the display).
Video (video recording; the icon
is displayed in the upper right corner of the display, the total remaining
recording time is given taking into account the current resolution in the HH:MM format (hours:minutes).
When switched on, the riflescope is in the Video mode. Toggle (switch) between the riflescope operating modes
with a long press of the REC (4) button. Switching between the modes is cyclical (Video–> Photo–> Video).
Photo Mode. Photographing an image.
•
Switch to Photo mode.
•
Press the REC button (4) briefly to take a photo. The image freezes for 0.5 sec - a photo is saved to the
internal memory.
USER MANUAL FOR DIGEX NIGHT VISION DIGITAL RIFLESCOPE
Video Mode. Recording a video.
•
Switch to the Video mode with a long press of the REC (4) button.
• Press the REC (4) button briefly to start video recording.
•
When the video recording starts, the icon
timer displayed in MM:SS (minutes:seconds) format will appear.
•
Pause/continue recording by briefly pressing the REC button (4).
•
Press and hold the REC (4) button to stop video recording.
Video files are saved to the built-in memory card in the following cases:
after turning off the video recording/photography;
if powering the riflescope off when recording was on;
when the memory card is overfilled during recording (Memory Full message appears on the display);
when connecting the riflescope in the Memory Card mode to the computer.
Notes:
You can enter and navigate the menu during video recording.
Recorded videos and photos are saved to the built-in memory card of the riflescope in the format img_xxx.jpg
(for photos); video_xxx. mp4 (for video) where xxx is a three-digit counter (for videos and photos).
The maximum duration of a recorded video file is five minutes. After this time expires, the video is recorded to
a new file. The number of recorded files is limited by the capacity of the unit's internal memory.
Regularly check free memory within the built-in memory card and move the footage to other storage media to
free up the memory card space.
WI-FI FUNCTION
The riflescope has a function enabling wireless communication with mobile devices (smartphone or tablet) via
Wi-Fi.
•
To enable the wireless module, enter the main menu by long pressing the controller button (6).
•
Rotate the controller ring (6) to select the Wi-Fi Activation menu item.
• Press the controller button (6) briefly to turn the Wi-Fi module on/off.
Wi-Fi is displayed in the status bar as follows:
Wi-Fi is switched off
Wi-Fi is switched on by the user, Wi-Fi connection in the riflescope is in progress.
Wi-Fi is switched on, there is no connection to the riflescope
Wi-Fi is switched on, there is connection to the riflescope
•
The riflescope is recognized by an external device under the name Digex_XXXX, where XXXX are the four last
digits of the serial number.
•
After entering the password (default: 12345678) on a mobile (see Wi-Fi Setup section of the Main Menu
Functions section of this manual for more information on setting a password) and setting up a connection,
the icon in the riflescope status bar changes to
•
Launch Stream Vision application on your mobile device (see page 21 of the manual).
•
Video broadcasting on a mobile screen starts after the viewfinder button on the mobile screen is activated.
will disappear and the REC icon as well as the video recording
.
