STADIAMETRIC RANGEFINDER
The Digex night vision digital riflescope is equipped with a stadiametric rangefinder, allowing you to determine
the approximate distance to an object if its size is known.
•
To select the Stadiametric Rangefinder function, enter the quick
access menu by briefly pressing the controller button (6).
•
Press the controller button (6) briefly to select the icon
•
The display will show the lines for measurements, the icons and
numbers of the measured distance for three objects.
There are three predefined values for objects:
Hare – 0.3 m high
Boar – 0.7 m high
Deer – 1.7 m high
•
Place the bottom fixed line under the object and rotating the controller ring (6), move the upper line relative
to the lower horizontal fixed line so that the object is located directly between the lines. The objects range is
automatically recalculated as the line is moved.
•
The system will exit from the Stadiametric Rangefinder function automatically if there is no measurement within
10 seconds.
•
To select a unit of measurement (meters or yards), go to the General Settings menu item =>Units of Measure
submenu.
•
The measured range value is rounded off before being displayed – for large range values up to 5 m, for shorter
range – up to 1 m.
• To exit the rangefinder mode, briefly press the controller button (6) or wait 10 seconds to exit automatically.
DISPLAY OFF FUNCTION
When this function is in use, the riflescope switches to the standby mode, which allows it
to be switched on quickly if necessary.
Options for operating with the Display Off function
Option 1. Riflescope off. It is necessary to power the riflescope on and activate the Display Off function.
•
Press the ON button (3) briefly to power the riflescope on.
• Activate the Display Off function: press and hold the ON button (3). The Display Off message with a
countdown will appear on the screen.
• Release the ON (3) button.
•
Press the ON (3) button briefly to deactivate the Display Off function (to activate the display).
Option 2. The Display Off function is activated; the riflescope should be switched off.
• Press and hold the ON (3) button. Display Off message with 3, 2, 1 countdown will appear on the screen.
•
Hold ON (3) button until the riflescope turns off (the riflescope turns off after counting down past 1).
PIP FUNCTION
The PiP function (Picture-in-Picture) allows you to see both a
magnified image in a special dialog box and the main image.
•
Press and hold the ZOOM button (5) to turn on/off the PiP
function.
•
To change digital magnification in the PiP dialog box, rotate the
controller ring (6), while the icon is visible on the screen.
•
The magnified image is displayed in a special dialog box, with the
full magnification being used.
USER MANUAL FOR DIGEX NIGHT VISION DIGITAL RIFLESCOPE
.
•
The rest of the image is displayed only with the optical magnification (digital magnification is off).
•
When PiP is turned off, the display shows the full magnification set for the PiP mode.
STREAM VISION
Digex night vision digital riflescopes support Stream Vision technology, which allows you to stream an image
from the display of your riflescope to a smartphone or a tablet PC via Wi-Fi in real time.
You can find detailed instructions on Stream Vision in the separate brochure or at the website www.pulsar-
vision.com.
Note: Software updates are provided for the riflescope. Updating is made possible via the Stream Vision
application.
To download the Stream Vision application scan the QR codes or follow the links:
USB CONNECTION
•
Press the ON button (3) briefly to power the riflescope on (the computer will not detect the riflescope if it is
turned off).
•
Connect one end of the USB cable to the riflescope MicroUSB port (10), and the other one to the port on your
computer.
•
The riflescope is detected by the computer automatically and no installation of drivers is required.
•
After a few seconds, two connection options appear on the display:
•
Power and Memory Card.
•
Rotate the controller ring (6) to select the connection option.
•
Press the controller button (6) briefly to confirm your selection.
Connection options
Power. Upon choosing this mode, your PC is used as an external power supply. The icon
status bar. The riflescope continues operating and all functions are accessible.
The battery pack installed in the riflescope is not charged.
Memory card. Upon choosing this mode, the computer detects the riflescope as a flash card. This mode is
designed to manage the files saved in the riflescope's memory. The riflescope's functions are not available
in this mode; the riflescope turns on. The device continues to operate after being disconnected from the
computer.
If a video was being recorded at the moment of connection, the recording will stop and will be saved.
USB disconnection
•
When the USB is disconnected from the riflescope in the Power mode, the riflescope stays on powered by
battery pack if it is sufficiently charged.
•
When the USB is disconnected from the riflescope in the Memory Card mode, the riflescope remains switched
on.
appears in the
