insTAllATiOn nOTes

A) C onnect the OUT hub -29- with the Line IN hub of your mixing console or amplifier. Optionally,
connect the digital OUT hub -30- with any device that features a digital IN hub, such as a CD
burner, MD recorder, digital mixer or audio card.
B) C onnect the hub -32- with the line cord and insert it into your outlet.
C) The Relay Play connection -25- can be used for Relay Play as well as for the Fader Start function.
>> For more details go to item -25-.
D) O ptionally, attach headphones to the 6.3mm stereo jack connection -26-. Use the control button
-27- to set the volume.
E) A fter making all connections, switch the device on using the ON/OFF switch -31-. If no CD is in the
drive, the Status LED above the drive -1- is continually illuminated.
F) P ress in Pause/Cue mode the Open/Close button -19- to open the CD tray and insert a CD. Press
the Open/Close button -19- once more to close the tray. The Status LED above tray flashes while
loading. As soon as the CD is loaded the Status LED goes out. Your CD-Player is ready now.
CAUTION: Do not try to close the CD tray manually - you could break the mechanism.

OPeRATiOn

1. CD Drive
For information regarding the drive, please refer to the above installation notes. (>>see F)
2. Play/Pause button
Press the Play/Pause button -2- to start play mode. Press again to activate Pause mode.
NOTE: Your CD player goes into Auto-Cue mode after being switched on.
>> see also item 8 or item 11/O. In this DJ-friendly mode, the Cue Point is automatically set on the
first signal of a music track.
3. Cue button
A Cue Point is a self-defined starting point, usually at the beginning of a beat. When activating the
Cue button -3- the CD player interrupts playing the track and returns to the last set Cue Point. To
set a Cue Point, follow either of the following two options:
I.) S earch the desired Cue Point using the Jog Wheel -18- or the Search Wheel -5- while in Pause
mode. You will access the Frame Search mode (fragmented repeats =1/75 minute) and can preci-
sion-set your Cue Points. Then press the Play/Pause button -2- to save the Cue Point. The player
returns to Play mode.
II.) W hile in Play mode, press the Loop IN button -12- at the desired point to save the Cue Point. The
player remains in Play mode. With a little practice, this is a faster way to set the desired Cue
Point. Press the Cue button -3- for the player to return to the Cue Point and go into Pause mode.
By pressing and holding the Cue button you will return to Play mode until you release the button
again. The player will then return to the Cue Point and go into Pause mode. Press the Play/Pause
button to permanently return to Play mode.
NOTE: when pressing the Cue button while in Play mode when no Cue Point has been set, the
player returns to the start of the track and goes into Pause mode (Auto-Cue). The player saves
the Cue Point which can be prompted with the Cue button for a single track only. when changing
to another track, the previous Cue Point will no longer be saved.
4. Track wheel
Use the Track Wheel -4- to select tracks. Press and turn the Track Wheel-4- at the same time to
move in increments of ten through the selection of tracks.
