Operation

Select operating mode

WARNING!
► Do not press the function selector switch
until the appliance has come to a complete
standstill . Switching between functions while
the tool is still rotating can damage the
appliance .
Function selector switch:
♦ Press and hold the release button
function selector switch
selector switch so that the required symbol
engages at the arrow mark:
Function
Drilling
Hammer drilling
Chisel position
adjustment
Chiselling
Adjusting the chisel position:
You can rotate the tool to the required position for
chiselling using this function .
♦ Turn the function selector switch
position .
♦ Turn the tool in the tool holder
quired position .
♦ Turn the function selector switch
position for the chiselling function .
■ │ GB │ MT
36
on the
. Turn the function
Symbol
to the
to the re-
to the

Preselecting the rotation speed

You can use the rotation speed preselector dial
to preselect the rotation speed . Level 1 (low rota-
tion speed) up to level 6 (high rotation speed)
Work out the correct settings by carrying out a test:
- Level 3–6: high speed: for hammer drilling/
chiselling in concrete or stone
- Level 1–3: low speed: for drilling in steel or
wood

Switching on and off

Switching the appliance on:
♦ Press the ON/OFF switch
Switching the appliance off:
♦ Release the ON/OFF switch

Changing the direction of rotation

♦ Change the direction of rotation by pressing
the rotation direction switch
or right .
.
.
towards the left
PKHAP 20-Li A1
