SYSTEM LAY-OUT
2
5
4
5
1 - R60 operator
2 - Radio antenna
3 - Blinker
4 - Photoelectric cells (external)
5 - Photoelectric cells (internal)
6 - Key selector
3 T
Gearmotor for moving industrial leaf-gates (not opening onto
6
public roads) with maximum weight of 12.000 kg.
The R60 is an irreversible gearmotor with a driving power which
can be varied in accordance with the pressure exerted by the
drive wheel on the ground.
5
Drive transmission between motor and gearmotor is by means
of V-belts to avoid mechanical damage due to recoil shock
transmitted from the gate at travel start, travel end, and during
direction change. The drive wheel tolerates approx. 10 cm level
difference as the gearmotor unit runs on vertical chromed ways.
Wheel/ground pressure is variable from 150 to 600 kg and is
1
maintained by special adjustable springs.
6
4
TECHNICAL DATA
Max. leaf length
Max. leaf weight
1
Average opening time 90°
Operating speed
EEC Power supply
5
Motor capacity
Power absorbed
Normative cycles
Daily cycles suggested
Service
Consecutive cycles guaranteed
Lubrification
Actuator weight
Operating temperature
1
Protection grade
Measurements in mm
14
14
ECHNICAL FEATURES
m
kg
s.
m/s. 0,164 (50Hz) - 0,196 (60Hz)
W
A
n°
n°
n°
kg
°C
IP
R60
15
12.000
116,5
400/380V 50-60Hz
1.100
3,1
50 - 100s/2s
300
100%
300
IP MELLANA 100
156
-10 ÷ +55°C
55
2
