Normal Operation—Mark II,
Q-Style Washer-Extractor
Monitor Normal Operation
When the door is closed, normal run displays similar to those below will appear.
Level not satisfied; no chemicals
actuated:
Level satisfied; no chemicals
actuated:
Chemicals or signal actuated:
Draining:
Extracting:
Data What it Means
10:38
Formula time remaining
F000
Formula number
S03
Step number
02:37
Step time remaining
dF/dC
Bath temperature (°F/°C) if
temp probes configured;
A=achieved, D=desired
*
Level achieved: * (below
low), 1, 2, 3
HC3
Water valves on: Hot, Cold,
2nd, 3rd
01:20
Drain time remaining
20RPM
Actual speed if configured
for RPM sensing and
variable speed
10:38 F0005S03 02:37
dF=A093/D140 * HC3
10:38 F0005S03 02:37
dF=A093/D140 LEV1
10:38 F0005S03 02:37
02-04 SOAP+ALKALI
DRAINING TO SEWER
01:20 20RPM
05:30 F0005S06 05:30
LO SPD EXT 0450 RPM
Data
Bath Steps
STEP 03
WAIT FOR LEVEL 2 Waiting for desired level
WAIT FOR LEV 10" Electronic level sensing waiting for
W=A00125/D00135
SPD 0
02-04
SOAP+ALKALI
Drain/Extract Steps
LO SPD EXT
10
MSOUPQNOAE/9433AV (5 / 5)
10:38 STEP 03 02:37
alternates
WAIT FOR LEVEL 2 HC3
with
10:38 STEP 03 02:37
alternates
dF=A093/D140
with
10:38 STEP 03 02:37
alternates
02-04 SOAP+ALKALI
with
05:30 EXTRACT 05:30
alternates
LO SPD EXT
with
What it Means
Step name
10 inches (or cm)
Metered water: A=achieved,
D=desired
If speed is programmable: 0=low,
1=high. Shows RPM for variable
speed machines.
Chemical number and name number
(alternates for multiple chemicals)
Chemical name (alternates for
multiple chemicals)
Extract speed (shows HI for single
speed)
SPD 0
0450 RPM
