ENGLISH
5.2 Manually Set-Up your Internet Connection Configuration
If your Country and/or ISP is not displayed in the "Quick Start" Connection Setup of the
CADSLR4(B)+ you need to define the connection manually.
Click on the "Config" button (7) in the "Quick Start" screen to enter the manual
configuration of the CADSLR4(B)+.
Note: You can also use the Manual Setup Configuration to modify advanced
connection settings!
The manual configuration page of the CADSLR4(B)+ will be shown on your screen:
9
To setup your connection, you need to enter the following information in the
connection setup screen:
1. Enter a name for your ADSL Connection.
2. Select the ADSL connection type. (PPPoE, PPPoA, etc.)
3. Select the correct encapsulation for the ADSL connection. (LLC, VC)
4. Enter the Username given by your provider.
5. Enter the Password given by your provider.
6. Set the correct VPI value for the ADSL connection.
7. Set the correct VCI value for the ADSL connection.
1
3
4 5
33
6
2
7
8
