Owner's Guide
C. At the end of each day
Do Not Use Petroleum Based Solvents, Iodophors Or
Phenolic Based Products. (Iodophors And Phenolics
Can Stain The Surface Of The Unit.) Clean Up All Liquid
CAUTION! Spills Immediately.
1. Remove all ultrasonic inserts, clean and sterilize as applicable.
2. Clean and disinfect the unit and peripherals as done before each
patient. Clean components by wiping with a soft cloth moistened
with a commercially available mineral deposit remover followed
by Alpet D2.
3. Flush All Water Lines Thoroughly.
4. Turn the unit OFF.
5. Close the main shut-off valve from the dental water supply.
D. Inspecting the power cord, water lines, filter and handpiece
• Periodically check and inspect the power cord, water lines, filter
and handpiece for damage, wear or clogging.
• Check connectors at both ends of the cord to make sure they are
fully seated.
E. Inspecting the scaler insert O-ring
• Inspect the rubber O-ring for wear and/or damage. O-rings will
wear over time due to repeated sterilization. When the O-ring is
worn and/or damaged, leakage will occur between the handpiece
and the scaler insert.
• Roll the worn or damaged O-ring over the laminate stack off the
scaler insert, and roll a new O-ring onto the scaler insert until
seated in the groove on the colored plastic grip.
F. Changing the fuse
Replace the fuse with the exact fuse type and rating to
avoid risk of fire.
WARNING!
To avoid risk of electric shock, unplug the unit before
attempting to change the fuse.
WARNING!
For 115 VAC 5 x 20 mm Slo-Blo 1.0 Amp, 250V
For 230/240 VAC 5 x 20 mm T-Type 0.5 Amp, 250V
• The fuse compartment is located immediately below the power
cord receptacle on the unit. Open the compartment with a small
screw driver (Fig. 9).
• Inspect the fuse (Fig.10). A good fuse is shown on the left of
Fig. 10, a blown fuse is shown on the right.
• Replace the fuse when necessary, and close compartment until a
click is heard.
V. Environmental/Storage Conditions
Environmental Conditions
• Intended for indoor use
• Maximum altitude : 2000m (6600 ft.)
• Temperature range:
5°C (41°F)
• Relative humidity:
50% @ 40°C (104°F)
Storage Conditions
The unit must be stored and transported within the
following conditions:
• Temperature range:
-40°C (-40°F)
• Relative humidity:
(non-condensing)
• Atmospheric pressure:
VI. Information for safety
Contraindications
The Biosonic US100R Ultrasonic Scaler should not be used for/on:
®
• Restorative dental procedures involving the condensation of
amalgam
• Surgical or endodontic procedures
• Patients highly susceptible to infections
• Patients with chronic respiratory problems
• Patients with dysphagia or swallowing difficulty with water flow
• Patients with cardiovascular disease with secondary pulmonary
disease or chronic pulmonary disease due to a risk of aspiration of
MOs in biofilm
Precautions
• Persons fitted with cardiac pacemakers or any other intra-corporeal
active medical device (e.g. insulin pump, defibrillator, etc.) have
been cautioned that some types of electronic equipment might
interfere with the operation of such devices.
instances of intra-corporeal medical electronic device interference
have ever been reported during use of the Biosonic
Ultrasonic Scaler, we recommend that the handpiece and cables
be kept at least 6 to 9 in (15 to 23 cm) away from any pacemaker
or pacemaker leads during use.
Clinicians should contact the pacemaker manufacturer or the
patient's physician for detailed information about the pacemaker.
40°C (104°F)
80% up to 31°C (88°F)
70°C (158°F)
100%
10%
1060hPa
500hPa
Although no
5
US100R
®
