Ottobock C-Leg 3C98-2 Information Für Träger Seite 32

Fine tuning of the standing angle (if required)
0° 7°
INFORMATION
Very slow extension (Fig. 3): Actively standing up from sitting at this speed would take more than 5 seconds.
Unblocking the standing angle
The standing angle can be unblocked at any time by either a quick extension movement
7°
0°
or complete extension (7 – 0°, Fig. 4).
4
INFORMATION
Quick extension (Fig. 4): Actively standing up from sitting at this speed would take less than 2 seconds. The
standing mode function remains turned on. A new standing angle can be selected at any time by repeating
steps "Adjusting the standing angle" / "Fine tuning of the standing angle". 1st mode remains active.
Explanation of arrow symbols:
Flexion / Extension
Very slow extension
Slow extension
Quick extension
32 | Ottobock
1. To optimize the angle, very slowly continue to extend the joint (70 –
7°; Fig. 3).
2. The blocked joint can be fully loaded in the flexion direction.
70°
3
C‑Leg
