Covered Sinuous Wire
(Do Not Activate Device
in Covered Position)
12. Advance the flexible tip up to the distal most extent of the clot. Uncover the
sinuous wire by unlocking, fully retracting the sliding lever and rotating the
sliding lever until an audible "click" is heard (refer to Figure 4). Confirm
device positioning within the treatment site via fluoroscopy. Press the
ON/OFF switch to activate rotation.
Deployed Position
(Uncovered For Device Activation)
Peripheral Vasculature
Sliding Lever Locked In
Uncovered Position
(Deployed)
Sliding Lever Locked in
Covered Position
Figure 3
Figure 4
