11.10.9 Clearing data-logger

This function deletes the stored data.
1. Select Settings > Data logger >Clear data logger and
confirm.
2. To clear the data-logger, select Confirm and confirm with
[OK].

11.11 Display settings

11.11.1 Changing the backlight color of the
display
The backlight color can be switched to red or green.
1. Loosen the screws (2) and open the cover.
2. Toggle the switch (13) to the desired position.
left
right
3. Close cover and tighten screws (2) with correct torque (22
Lbs. In. / 2.5 Nm).

11.11.2 Changing the display contrast

1. Select Settings > Instrument > Display > Display
contrast and confirm.
2. Change the contrast and confirm.

11.11.3 Changing the display mode

1. Select Settings > Instrument > Display > Display mode
and confirm.
2. Select the desired mode and confirm.
Standard
Non-display
If an alarm is triggered, the display shows the current gas
concentration and the red LED blinks regardless of the
selected display mode.

11.11.4 Performing display test

1. Select Settings > Instrument > Display > Displaytest
and confirm.
2. Select Enable or Disable and confirm.
When enabled, the display is shown inverted and all the
LEDs are lit.
Instructions for use |
Dräger PointGard 2000 Series
backlight color red
backlight color green
Shows the standard display.
Shows the start screen and
the applicable symbols.

Configuration of integrated alarm devices

12 Configuration of integrated alarm
devices

12.1 DIP switch

The 5 pins on the DIP switch are used to configure the alarm
patterns of integrated alarm devices.
Pin ON
Horn is active on A2
1)
1
alarms.
Horn is active on A1
1)
2
alarms.
3 Strobe alarm pattern for
green/red strobe combina-
tion.
4 Horn is active.
5 Horn tone: Continuous
1) Pins 1 and 2 are not applicable for instruments with green/red strobe
combination.
DIP switch default settings for amber/red strobe
combination
1 2
ON OFF
DIP switch default settings for green/red strobe
combination
1 2
ON OFF

12.1.1 Setting the DIP switch pins

1. Open the instrument.
2. Toggle the DIP switch pins:
to the left
to the right
3. Close the instrument.
4. Commission the instrument.
OFF
Horn is not active on A2
alarms.
Horn is not active on A1
alarms.
Strobe alarm pattern for
amber/red strobe combina-
tion.
Horn is not active.
Horn tone: Pulsating
Pins
3 4
OFF ON OFF
Pins
3 4
ON ON OFF
ON
OFF
|
