About the display
The graphical display at the bottom of the iBOTs tab shows exactly where in
the system each active iBOT is at any time during the run. The green column
on the far right represents the loading column.
The color of each iBOT indicates its current status (Figure 4-20):
Figure 4-20: iBOT colors used in graphical display
A white rectangle on top of an iBOT indicates that the iBOT is carrying an item.
Click on an iBOT in the display to see its status information in the top window.
4.1.6.4. ELC tab
Shows the status of the ELC. In Figure 4-21, it appears green, which means it
is currently connected and functioning properly. If it appeared red, it indicates
that there is a problem with connectivity.
Note: The "Alerts/Events" tab shown in the above figure is not available at the
operator level.
Operation
(Green) The iBOT is sufficiently charged
(Yellow) The iBOT is in need of attention (low on power)
(Red) The iBOT has jammed
Figure 4-21: ELC tab
