3.2. Options and Configurations
3.2.1. Base Configuration
The Sure Sort™ base system, shown in Figure 3-3, includes:
• A Host computer:
- Microsoft
64bit / 8Gb / Raid1 SSD
drives
• Induct conveyor module
• Stacker base module with bins
(available in depths of 4", 7" and
12"). The actual amount and
size of bins will be determined in
the purchase agreement.
• iBOTs (the actual amount of
iBOTs will be determined in the
purchase agreement).
• 2 large tubs
3.2.2. Options
Optional enhancements include:
OPEX Barcode tunnel
on the imaging conveyor, regardless of their orientation. Details on this option
can be found at
Return conveyor module
Items that come back are mostly items that were not scanned properly. The
return conveyor is motorized and moves items with a conveyor belt.
Overview
®
Windows10 pro /
- an array of cameras meant to read barcodes from items
"The Optional OPEX Barcode Tunnel" on page
- used to return a rejected item back to the operator.
Sure Sort™ Operator Manual
OPEX Corporation
Expansion module, typical
4'-3"
(130 cm)
5'-1"
(155 cm)
8'-9"
(267 cm)
Power
cable
Base stacker side view
Notes:
1. All dimensions are approximate and are provided for reference only.
2. Allow for at least 36" (91.4 cm) walking/working space around all sides of machine.
3. There must be 18" (45.7 cm) minimum clearance from top of machine to any sprinklers
in the area.
Figure 3-3: Sure Sort™ base system
Base unit with scan tunnel and eleven
expansion modules, typical
46'-11"
(1430 cm)
10'-10"
(330.2 cm)
94.
89
