Cola SPRINT maiolica Installations-, Bedienungs- Und Wartungsanleitung Seite 44

Every installation must provide for an easily accessible technical space for periodical maintenance.
The stove is provided with 6 adjustable feet to facilitate positioning on not perfectly flat floors. To adjust the height,
tilt the stove slightly and turn the feet as required.
The stove is supplied with the ambient sensor fixed through a wrapper on the back of the stove; we recommend to
remove the wrapper and to locate the sensor in the best position possible as to improve the temperature registration
in accordance with the ambient context and the length of the cable.
As for temperature registration done at a certain distance we reccomend to install the ambient thermostat/ambient
programming clock-thermostat – see. par.4.8.
- The stove cannot be installed in bedrooms, bathrooms and in general in rooms where another heating
unit is already installed without an independent air inflow.
- With wooden floors, install a floor protection base in conformity with the current regulations.
- Suitable fire-prevention devices should be arranged for any eventuality.
- Do not install the stove in places with an explosive atmosphere.
Antiwind
grille
Flue
Flue connection
Air inlet
min. 100 cm²
Floor protection base
44
A = 200
mm
B = 200
mm
C = 1500
mm
D = 200
mm
SPRINT ** maiolica
