4) TIG-weld as desired
NOTE: The RED Ip and
GREEN I leds will stay on
1
continuously during the
weld process and the dis-
play will visualize the cur-
rent value used for welding
TIG PULSATING WELDING WITH
CYCLE FUNCTION ON
Two different levels of pulsating current
(I and I ) can be used for welding with
1 2
this function. Here also welding can be
done in the two ways ON PULSE and
EASY PULSE.
It is also necessary to set the 2
PEAK CURRENT (I2p) (apart from the
pulsating parameters Ib, Ip, f) with the
CYCLE function on. The other 2
pulsating parameters (BASIC CUR-
RENT I and FREQUENCY f) are
2b
obtained in synergy. FREQUENCY
remains constant while the 2
BASIC CURRENT (I ) is in proportion to
2b
st
the ratio between the 1
ON PULSE AND EASY PULSE
METHODS
1) Start up the welder by turning the
main switch to position I
2) Press the "weld mode"
button and set on
CYCLE
ON PULSE METHOD
3A)Press the "pulsation"
button until the ON
PULSE function is
working
4A)Press the SET key until
the GREEN led I
the RED led I
flashing; adjust the 1
level PEAK CUR-
RENT I
1p
value by turning the
special dial.
nd
level
nd
level
nd
level
level currents.
and
1
will start
p
st
(5 ÷ 250 A);
WARNING: go on to point 8)
EASY PULSE METHOD
5A)Press the SET key until
nd
the RED led of the 2
level of PEAK CUR-
RENT I (5 ÷ 250 A)
2p
starts flashing
• Adjust the parameter by
turning the special dial
6A)Press the SET key until
st
the RED led of the 1
level BASIC CUR-
RENT (5 ÷ 125 A)
starts flashing
• Adjust the parameter by
turning the special dial
7A)Press the SET key until
the RED led of the
PULSATION FRE-
QUENCY (0.5 ÷ 500
Hz) starts flashing
• Adjust the parameter by
turning the special dial
3B)Press the "pulsation"
button until the EASY
PULSE function is
working
19
4B)Press the SET key until
the GREEN led I
the RED led I
flashing; adjust the 1
level PEAK CUR-
RENT I
1p
value by turning the
special dial.
WARNING: with EASY PULSE working
and adjusting the value of the 1
PEAK CURRENT (I ) you will have the
1p
values of the other 1st level parameters
(I ,f) in synergy
1b
5B)Press the SET key until
the RED led of the 2
level PEAK CUR-
RENT I
2p
starts flashing
• Adjust the parameter by
turning the special dial
WARNING: adjusting the value of the
nd
2 level PEAK CURRENT (I
EASY PULSE is working, you will have
the values of the other 2nd level para-
meters (I , f) in synergy
2b
8) If you want a test weld,
the led of the selected
parameter will flash
and the value of the
parameter being set
will be visualized on
the display while this is
being done
9) Keep pressing the SET
key for more than 1
second to leave the
weld parameter setting
phase
10) Use the CYCLE function for PUL-
SATING TIG welding
and
1
will start
p
st
(5 ÷ 250 A);
st
level
nd
(5÷200 A)
) while
2p
