PaX-i3D Smart(PHT-30LFO) User Manual
6. Adjust the height of the unit to suit the patient by pressing the column up/
down button or switch (optional).
After adjusting the column to suit the height of the patient, fit
the ear rods along the patient's ear canals.
CAUTION
7. Place the ear rods along the patient's ear canals. Make sure that the ear
rods are comfortably, yet firmly, in place.
30-40
9. Click the Ready button after the patient has been properly positioned. No
X-Ray will be emitted at this point.
10. Proceed to section 4.3 Initiating X-Ray Exposure.
4 Acquiring CEPH Images
8. Ask the patient to swallow any saliva in
his/her mouth and tilt his/her neck back
30° - 40°, with the mouth closed, until
X-Ray exposure is complete.
47
