4.2.2
PaX-i3D Smart(PHT-30LFO) User Manual
PA
Follow the procedure below to correctly position the patient.
4. Guide the patient to the CEPH unit.
After adjusting the column to the patient's height, fit the ear
rods along the patient's ear canals.
CAUTION
4 Acquiring CEPH Images
1. Turn the CEPH ear rods to PA mode position as
shown in the figure.
2. Widen the distance between the two ear rods.
3. The nasal positioner should be flipped to the side
and upward to prevent it from obstructing the image
acquisition.
5. Ask the patient to stand upright facing
the sensor.
Make sure that the patient's shoulders are
level and that his/her neck is relaxed.
6. Adjust the height of the unit to suit the
patient by pressing the column up/down
button or switch (optional).
43
