4 Acquiring CEPH Images
38
3. (For One-shot CEPH only) Do the selections that follow.
- FOV Size: Select the FOV size.
FOV
Large
: 12x10 (inches)
: 30.48x25.40 (cm)
Medium
: 9x10 (inches)
: 22.86x25.40 (cm)
Small
: 8x8 (inches)
: 20.32x20.32 (cm)
- Exposure Time: Scan time can be adjusted by resolution of 0.1 sec in the
range of 0.7 sec to 1.2 sec.

4. The patient's gender will be automatically selected according to the patient
information registered in EasyDent / EzDent-i. Nevertheless, ensure that this
information is correct.
Age Group
Adult
Full size
Region of the no interest of the rear part of the
head is eliminated to minimize the X-ray expo-
sure area.
For Child

Child
Man
Woman
Details

VATECH's Standard
≤ 12
≥ 13
PaX-i3D Smart(PHT-30LFO) User Manual
