Controls For Seca 234 Measuring Rod (Optional) - Seca 232 n Gebrauchsanweisung Und Garantieerklärung

No. Control
6
Status LED
7
Foot screw
Electrical
8
connection (with
protective cap)
Battery
9
compartment
10
USB interface
Power supply
11
connection

3.2 Controls for seca 234 measuring rod (optional)

No. Control
1
Head stop
2
Connector
3
Display
4
hold key
Measuring rod with
5
scale
6
Foot stop
7
Handle
44 •
Indicates the status of data recording and data transmission:
• Illuminated in green: Identification or measuring procedure started.
• Flashing green (approx. 5 seconds): Measured results being sent to the HIS (depending on
setting).
• Illuminated in green (approx. 5 seconds): Measured results successfully sent to the HIS
(depending on setting).
• Illuminated in red (approx. 5 seconds, see "Data transmission (models with a WiFi interface)"
from page 38):
- ID found in hospital information system (HIS) or in seca software.
not
- Device has saved measured results to the clipboard.
not
- Measured results have
NOTE
The data recorded and transmitted are set in the configuration software. If you have any
queries, please contact your administrator or hospital technician.
4 pcs, for precise alignment
For connecting a digital measuring rod
Takes type AA batteries, 1.5 V
For connecting a barcode scanner
For connecting the power supply unit
1
For positioning the baby
For connecting to a scale
Display element for measured results
Sends measured result to the connected scale
For reading off length
For positioning the baby
For moving the foot stop
Function
been sent to an HIS or to seca software.
not
2
4
3
Function
5
7
6
