3M™ MicroTouch™ Display M1700SS User Guide
Figure 4. Removing the Cable Connector Cover
Lift this cover slightly so that the tabs are up against the rear of the display to keep
5.
them from catching on the cables below. Tilt the cover down as you slide the cover
out from behind the support rods.
Figure 5. Uncovered Cable Connections
Document #19-268 Rev AN
8
Keep tabs against
display
