Other Input/Output Part
● USB Interface
B Type Connector
Supports USB 1.1 and 2.0 Mass Storage Device Class.
● CompactFlash Slot
Supports Type I only.
Effect Unit Part
Effect Type:
3-BAND SHELVING EQ, 6-BAND GRAPHIC EQ, NOISE
GATE, ENHANCER, COMPRESSOR AND DE-ESSER, NO
EFFECT
Control
• Power Switch
• Hold Switch
• Input Gain Knobs: CH1–CH4
• Monitor Level knob
• Input Level Switches:
CH1/2, CH3/4 (LINE/MIC Level)
• Phantom Power Switches: CH1/2, CH3/4
• Limiter Switch
Others
● Display
128 x 64 dots Graphic LCD (backlit LCD)
● Power Supply
AC Adaptor, Alkaline dry battery LR6 (AA) type x 8, or
Nickel Hydrogen battery (HR15/51) x 8
● Power Consumption
2000 mA
* In the interest of product improvement, the specifications and/or appearance of this unit are subject to change without prior notice.
● L Connector
Receiving only.
Supports Start/Stop Sync only.
Not Supports Timecode.
* Available to either recording or playing
* Not available to recording in 96 kHz sampling frequency.
• Scrub (Value)/Shuttle Dial
• Transport Buttons:
PREV, NEXT, STOP, PLAY, PAUSE, REC
• Marker Buttons: CLEAR, PREV, NEXT, MARK
• Function Buttons: WAVE EDIT, EFFECTS, SYSTEM
• A-B Repeat Button
• Display Button
● Dimensions
240 (W) x 217.4 (D) x 77.1 (H) mm
9-1/2 (W) x 8-9/16 (D) x 3-1/16 (H) inches
● Weight (with batteries)
1.7 kg
3 lbs 12 oz
● Accessories
Owner's Manual
AC Adaptor
USB cable
Carrying Case
Main specifications
85
