Inserting and removing a card
fig.CFslot.eps
Inserting
1
Switch off the R-4's power.
2
Open the [MEMORY CARD] slot cover, and
insert the CompactFlash card with its top surface
facing upward.
Insert the CompactFlash card all the way into the
slot.
* If you attempt to forcibly insert the card in the wrong
direction, the R-4 and the CompactFlash card may be
damaged. Use caution.
3
Close the [MEMORY CARD] slot cover.
Removing
1
Switch off the R-4's power.
2
Make sure that data is not being written to or read from the CompactFlash card.
3
Open the [MEMORY CARD] slot cover, press the eject button, and remove the CompactFlash card.
Formatting a CompactFlash card
Before you use a CompactFlash card with the R-4, you'll need to format the card. For the formatting
procedure, refer to page 68 of "Executing HDD Utility or CF Utility commands" (p. 68).
CompactFlash cards formatted on a device other than the R-4 may not work correctly on the R-4.
The CompactFlash card must be formatted in FAT16 format.
As an exception, you should use your Macintosh (not the R-4) to format the CompactFlash
card if you will be using the card in Mac OS 9.
With the surface of the
CompactFlash card facing
upward, insert it all the way
into the slot
Appendix
71
