Effects setting

Effects

1: 3-Band EQ
Parameter
No.
name
1 LOW GAIN
2 MID FREQ.
3 MID Q
4 MID GAIN
5 HIGH GAIN
6 LEVEL
2: Graphic EQ
Parameter
No.
name
1 125Hz
2 250Hz
3 500Hz
4 1kHz
5 2kHz
6 4kHz
7 Level

3: Noise Gate

Parameter
No.
name
1 LO-CUT
2 THRESHOLD
3 LEVEL
56
Range of values
-12dB–0dB–+12dB
200Hz, 250Hz, 315Hz,
400Hz, 500Hz, 630Hz,
800Hz, 1kHz, 1.25Hz,
1.6kHz, 2kHz, 2.5kHz,
3.15kHz, 4kHz, 5kHz,
6.3kHz
0.5, 1.0, 2.0, 4.0, 8.0
-12dB–0dB–+12dB
-12dB–0dB–+12dB
0 - 120
Range of values
-12dB–0dB–+12dB
-12dB–0dB–+12dB
-12dB–0dB–+12dB
-12dB–0dB–+12dB
-12dB–0dB–+12dB
-12dB–0dB–+12dB
0–120
Range of values
OFF, 40Hz, 55Hz, 63Hz,
80Hz, 100Hz, 125Hz, 160Hz,
200Hz, 250Hz, 315Hz,
400Hz, 500Hz, 630Hz,
800Hz, 1kHz
OFF,1–100
0–120
Default
Explanation
values
Adjusts the gain of the low-range
0dB
equalizer.
Specifies the center frequency of the
1kHz
mid-range equalizer.
Specifies the width of the region cen-
tered on the Mid Freq for which the
2.0 gain will change. Higher Q settings
will narrow the region in which the
change occurs.
Adjusts the gain of the mid-range
0dB
equalizer.
Adjusts the gain of the high-range
0dB
equalizer.
100 Adjusts the overall volume.
Default
Explanation
values
0dB Adjusts the gain at 125 Hz.
0dB Adjusts the gain at 250 Hz.
0dB Adjusts the gain at 500 Hz.
0dB Adjusts the gain at 1 kHz.
0dB Adjusts the gain at 2 kHz.
0dB Adjusts the gain at 4 kHz.
100 Adjusts the overall volume.
Default
Explanation
values
Cuts unwanted low-frequency noise
100Hz
such as wind.
Specifies the volume threshold be-
20
low which the sound will be cut.
100 Adjusts the overall volume.
