Application guide

Before you record using the R-4, you'll need to make a variety of settings so it's set up in a way that's
appropriate for your recording situation and purposes.
This section gives several actual examples of applications. For details on connections refer to "Recording"
(p. 27). Here we will explain the settings you'll need to make on the R-4.
Connecting an external mic for CD-quality stereo
recording
This is a basic form of recording.
■ Panel settings
Input level select switch
Phantom power switch
■ Recording Setup
Input Select
Rec Freq.
Rec Bit
Rec Mode
Pre Recording
Project Name
MIC
ON if you're using a condenser mic that requires phantom power; otherwise
OFF
Analog
44.1 kHz
16 bit
STEREOx1
OFF
Date
75
