8. TECHNICAL CHARACTERISTICS: ____________________________________________________________________________________

TECHNICAL SPECIFICATIONS:

Standard working voltage
230V AC – 50 Hz.
Cable: 3 x 1.5 mm
Smart+ 60 / 42350
Smart+ 100 / 42351
Smart+ 160 / 42352
Fuse
Smart+ 60 / 42350
Smart+ 100 / 42351
Smart+ 160 / 42352
Output voltage
8 – 9V DC / Cable 3 x 4 mm
Smart+ 60 / 42350
Smart+ 100 / 42351
Smart+ 160 / 42352
Production
Smart+ 60 / 42350
Smart+ 100 / 42351
Smart+ 160 / 42352
Minimum recirculation flow
Smart+ 60 / 42350
Smart+ 100 / 42351
Smart+ 160 / 42352
Electrode number
Smart+ 60 / 42350
Smart+ 100 / 42351
Smart+ 160 / 42352
Net weight
Smart+ 60 / 42350
Smart+ 100 / 42351
Smart+ 160 / 42352
Dimensions
2
, leng. 2 m.
0.58 A
1.11 A
1.45 A
2A T (5x20 mm)
3.15A T (5x20 mm)
4A T (5x20 mm)
2
, leng. 2 m.
12 A (2x6 A)
24 A (2x12 A)
32 A (2x16 A)
10 – 12 g./h.
20 – 24 g./h.
25 – 32 g./h.
3
2 m /h.
3
4 m /h.
3
6 m /h.
5
7
7
11 Kg.
13 Kg.
15 Kg.

GENERAL FEATURES:

Control system
•
Microprocessor.
•
Membrane keypad with control keys and
operation indication leds.
•
Control I/O: 3 inputs (potential-free conact
type) for monitoring the state of the
automatic cover, external flow detector and
the ORP/Residual Chlorine controller).
•
Cell output: production control (11 discrete
levels).
•
Salinity range / Temperature: 4 ... 6 g/l. /
o
+15 C – 40
Self-cleaning
Automatic polarity switch
Working termperature
o
0 C to +40
Cooling: natural convection
Material
•
Power supply
Blue ABS
Aluminium
•
Electrolysis cell
Blue methcrylate
Flow switch
Casing: plastic (Noryl PPO)
Paddle: plastic (Noryl PPO)
Shaft: stainless steel 1.4571
Magnet: hard ferrite
O-ring: EPDM
IP 54
Cable 3 m.
6.
16
o o o
C (59 F – 104 F)
o
C
