2 x Product description
Profile connector FIX-VB
Profile connector (
mounting DIN rails:
– Connection sheets (2x)
– Internal hexagon wrench
– Fixing screws (4x)
Solaris flat collectors V26A and H26A
Collector V26A (
– H x W x D: 2000 x 1300 x 95 mm, weight: approx. 41 kg
Collector H26A (
– H x W x D: 1300 x 2000 x 95 mm, weight: approx. 44 kg
CON V
Collector connection package (
ready-for-connection connection of one other collector incl.
mounting material for the fastening of two collectors
6
16 42 22) for interconnecting
16 43 04):
16 43 05):
16 42 13) for the
Fig. 2-8 Profile connector FIX-VB
Fig. 2-9 Solaris flat collector (marked V26A)
Fig. 2-10 Collector connection package CON V
