Materials for the collector assembly

CON F
Connection cable Solaris (
flat roof installation
CON FE
Extension for alternating collector connection
( 16 47 09) in flat roof installation
Collector mounting rails
FIX-130 (
– two mounting rails for a V26A collector
FIX-200 (
– two mounting rails for a H26A collector
FIX-260 (
– two mounting rails for two V26A collectors
FA ROTEX Solaris flat roof - 05/2007
16 47 13) for
16 42 25):
16 42 26):
16 42 27):
2 x Product description
Fig. 2-5 CON F
Fig. 2-6 CON FE
Fig. 2-7 Collector mounting rails
