Technical Data

6.2 General Technical Data

6.2.1

Control functions

Control function A
Control function B
6.2.2

Materials

Valve housing
Actuator
Sealing elements
Spindle seal
(with silicone grease)
Seat seal
Spindle
6.2.3

Connections

Control air connection 45° hose plug-in connection 4/2 M5
(Recommendation)
Medium connection
6.2.4

Media

Control medium
Flow media
6.2.5

Installation position

any position, preferably with actuator face up
Closed by spring force in rest position.
Opened by spring force in rest position.
316L
1.4404
FKM
PTFE-V rings with spring compensation
PTFE
1.4401/1.4404
Order no. 903383
G3/8 and NPT3/8 - socket connection
G1/2 - external thread
Welded support in accordance with EN ISO 1127/ISO 4200, DIN 11850 series 2,
ASME BPE
Other connections on request
neutral gases, air
Water, alcohols, oils, fuels, hydraulic fluids, saline solutions, lyes, organic
solvents, steam, air, neutral gases
37
