Parameterizing Steps
Input in Motor order
P097 number
(MPRD)
71 1PH4168-4_F_
72 1PH7107-2_G_
73 1PH7167-2_G_
74 1PH7284-_ _B_
75 1PH7284-_ _D_
76 1PH7284-_ _F_
77 1PH7286-_ _B_
78 1PH7286-_ _D_
79 1PH7286-_ _F_
80 1PH7288-_ _B_
81 1PH7288-_ _D_
82 1PH7288-_ _F_
for future applications
83 to 99
100 1PL6284-_ _D_
101 1PL6284-_ _F_
102 1PL6286-_ _D_
103 1PL6286-_ _F_
104 1PL6288-_ _D_
105 1PL6288-_ _F_
106 to
for future applications
127
9-44
Rated Frequency
speed f n [Hz]
n n [rpm]
1750 59.4
2300 78.6
2300 77.4
500 17.0
1150 38.6
1750 58.7
500 17.0
1150 38.6
1750 58.7
500 17.0
1150 38.6
1750 58.7
1150 38.9
1750 59.0
1150 38.9
1750 59.0
1150 38.9
1750 59.0
Table 8 Motor list 1PH7 (=1PA6) / 1PL6 / 1PH4
Current Voltage
I n [A] U n [V] M n [Nm]
117.0 400
24.8 398
85.0 398
144.0 400
314.0 400
393.0 400
180.0 400
414.0 380
466.0 400
233.0 400
497.0 385
586.0 400
478.0 400
616.0 400
637.0 380
736.0 400
765.0 385
924.0 400
6SE7087-6KD60
Operating Instructions
04.2006
cos ϕ
Torque i
µ
[%]
333 0.82 36.8
50 0.80 48.8
183 0.84 47.1
1529 0.87 41.7
1414 0.82 50.3
1228 0.86 41.5
1909 0.86 43.3
1745 0.81 52.7
1474 0.87 39.5
2481 0.87 42.6
2160 0.82 50.7
1856 0.87 39.9
2325 0.89 32.6
2019 0.90 26.3
2944 0.89 33.6
2429 0.91 24.7
3607 0.89 32.4
3055 0.91 25.1
