Materials
Tank casing
Pump casing
Impeller
Seals
Motor shaft
5.

Application

/
Conel wastewater lifting station FLOWBOX-N according to DIN EN 12050-2, installed above
ground to drain sinks, washing machines and dishwashers, shower basins and bathtubs.
/
The FLOWBOX-N is exclusively for private use for the pumping of clear water, chemical-neutral
grey water, faecal-free water, and domestic sewage with solids of up to max. 12 mm ø, or bet-
ween a solid rate of up to 0.5%, without aggressive, oily or fibrous materials.
/
Not suitable for corrosive, flammable, gaseous or explosive fluids, wastewater from urinals and
toilets as well as faecal water. Fluids containing sand or other substances reduce the service
life of the pump. Not intended for condensation from ventilation systems, heat pumps and
condensing boilers, and brine from water softening systems.
/
T his product is suitable for pumping fluids with medium temperature of 40 °C or up to a
maximum of 60 °C during short term operation. If the pump is supplied with dirty water from
washing machines the alkaline cooling must not be switched off for energy saving reasons. If
the alkaline cooling is not switched on, this may cause damage to the submersible pump, for
which we cannot assume any guarantee or honour the warranty in that case. If necessary,
please contact the manufacturer of the device for the state of supply intended for the
connection. Our systems are checked in accordance with EN 12050 LGA and conform to the
current standards. Also note that the maximum inlet temperature in the public sewer system is
35 °C and that you must ensure that the water is cooled accordingly.
/
The noise emission value is less than 70 dB (A).
/
As with any electrical appliance, if due to the specific use a failure of the pump can cause da-
mage (for example in the case of faulty operation, due to a power failure or a technical defect).
If this can result in consequential damage an alternative system (for example emergency power
supply, double pumping station, network-independent alarm) must be available. In that case, to
prevent uncontrolled water leakage, the high level alarm sensor integrated in the tank must be
connected to the optional alarm system with cable (KBN: FLOWBOXSAFEKIT) available as an
accessory.
Polypropylene
Polypropylene
Polyamide
NBR/EPDM
Stainless steel 1.4057 (AISI 431)
