6.2 Level control

Switch-on level
Switch-off level

6.3 Materials

Tank casing
Pump casing
Impeller
Seals
Motor shaft
Performance curve
Abmessungen
> Conel wastewater lifting station FLOWBOX according to DIN EN 12050-2, installed
above ground to drain sinks, washing machines and dishwashers, shower basins
and bathtubs.
> The FLOWBOX is exclusively for private use for the pumping of clear water,
chemical-neutral grey water, faecal-free water and domestic sewage with solids
of up to max. 12 mm ø, or between a solid rate of up to 0,5%, without aggressive,
oily or fibrous materials.
> Not suitable for corrosive, flammable, gaseous or explosive fluids, wastewater
from urinals and toilets as well as faecal water. Fluids containing sand or other
substances reduce the service life of the pump. Not intended for condensation
from condensing boilers and brine from water softening systems.
> This product is suitable for pumping fluids with medium temperature of 40
°C or up to a maximum of 60 °C during short term operation. If the pump is
supplied with dirty water from washing machines the alkaline cooling must not
be switched off for energy saving reasons. If the alkaline cooling is not switched
on, this may cause damage to the submersible pump, for which we cannot
assume any guarantee or honour the warranty in that case. If necessary, please
contact the manufacturer of the device for the state of supply intended for the
connection. Our systems are checked in accordance with EN 12050 LGA and
conform to the current standards. Also note that the maximum inlet temperature
Level control | Materials | Application
100 mm
50 mm
Polypropylene
Polypropylene
Polyamide
NBR/EPDM
Stainless steel 1.4028 (AISI 420)
See appendix fig. 1
See appendix fig. 2

7. Application
