TQ-800BA MODEL
The TQ-800BA model allows for quick single-sided toasting
of sliced bagels or bun products up to 51 mm (2") thick
and 245 mm (9-5/8") wide. Most products can be toasted in as little
as 30 seconds. Capacity is up to 800 bagel or bun halves per hour.
Toasts cut side facing up.
TQ-800HBA MODEL
The TQ-800HBA model is designed to provide the flexibility
and performance to toast one side of sliced bagels or bun products
in as little as 30 seconds. Capacity is more than 800 bagel or bun
halves per hour. Toasts cut side facing up. Maximum product size
allowed is 70 mm (2-3/4") thick and 245 mm (9-5/8") wide.

PLUG CONFIGURATIONS

Units are supplied from the factory with an electrical cord and plug
installed. Plugs are supplied according to the applications. See 3 .
DIMENSIONS – TQ-10 & TQ-15 MODELS
Width
Model (A)
TQ-10 368 mm 451 mm
(14-1/2") (17-3/4")
TQ-15 368 mm 451 mm
(14-1/2") (17-3/4")
Depth Leg Height Height
(B) (C) (D)
102 mm 349 mm
(4") (13-3/4")
102 mm 349 mm
(4") (13-3/4")
MODEL DESCRIPTIONS
TQ-1200 MODEL
The TQ-1200 is a high speed toaster which has an accelerated
conveyor system allowing faster toasting during periods
of high demand. Two slices of bread products can be toasted
in as little as 15 seconds. This model is capable of toasting bread
products up to 38 mm (1-1/2") thick and 245 mm (9-5/8") wide.
Plug unit into a properly grounded electrical outlet
of the correct voltage, size and plug configuration. If the plug
and receptacle do not match, contact a qualified electrician
to determine the proper voltage and size and install the proper
electrical outlet.
To prevent any injury or damage do not pull unit
by power cord.
To prevent any injury, discontinue use if power cord is frayed
or worn.
DIMENSIONS – TQ-400, -405, -800, -805 &
-1200 SERIES
Width
Model (A)
TQ-400 368 mm
(14-1/2")
TQ-405 368 mm
(14-1/2")
TQ-400BA 368 mm
(14-1/2")
TQ-800 368 mm
(14-1/2")
TQ-805 368 mm
(14-1/2")
TQ-800H 368 mm
(14-1/2")
TQ-800BA 368 mm
(14-1/2")
TQ-800HBA 368 mm
(14-1/2")
TQ-1200 368 mm
(14-1/2")
6

SPECIFICATIONS

WARNING
WARNING
WARNING
Depth Leg Height Height
(B) (C)
451 mm 25 mm 381 mm
(17-3/4") (1")
451 mm 25 mm 381 mm
(17-3/4") (1")
451 mm 25 mm 381 mm
(17-3/4") (1")
58 cm 25 mm 419 mm
(22-3/4") (1") (16-1/2")
578 mm 25 mm 419 mm
(22-3/4") (1") (16-1/2")
578 mm 25 mm 419 mm
(22-3/4") (1") (16-1/2")
578 mm 25 mm 419 mm
(22-3/4") (1") (16-1/2")
578 mm 25 mm 419 mm
(22-3/4") (1") (16-1/2")
578 mm 25 mm 419 mm
(22-3/4") (1") (16-1/2")
Form No. TQ2CEM-0903
(D)
(15")
(15")
(15")
