Hatco TOAST-QWIK TQ-10 Installations- Und Bedienungshandbuch Seite 10

Model Voltage
TQ-800 208
240
200
220-230 (CE)
230-240 (CE)
TQ-805 230-240 (CE)
TQ-800H 208
240
200
220-230 (CE)
230-240 (CE)
TQ-800BA 208
240
200
220-230 (CE)
230-240 (CE)
TQ-800HBA 208
240
200
220-230 (CE)
230-240 (CE)
Shaded area reflects export models only.
NOTE: TQ-800, TQ-805, TQ-800H, TQ-800BA and TQ-800HBA 220-230 Volt (CE) and 230-240 Volt (CE) available with either
CEE 7/7 Schuko, BS 1363 or AS 3112 plug. See Plug Configurations for details.
Model Voltage
TQ-1200 208
240
ELECTRICAL RATING CHART – TQ-800 SERIES
Hertz Watts
60 3330
60 3330
50/60 3080
50/60 3046-3330
50/60 3330-3625
50/60 3330-3625
60 3330
60 3330
50/60 3080
50/60 3046-3330
50/60 3330-3625
60 3280
60 3280
50/60 3033
50/60 2817-3080
50/60 3080-3354
60 3280
60 3280
50/60 3033
50/60 2817-3080
50/60 3080-3354
ELECTRICAL RATING CHART – TQ-1200 MODELS
Hertz Watts
60 4030
60 4030
Amps Plug Configuration
16.0 NEMA 6-20P
13.9 NEMA 6-20P
15.4 AS 3112
13.8-14.5 See Note
14.5-15.1 See Note
14.5-15.1 See Note
16.0 NEMA 6-20P
13.9 NEMA 6-20P
15.4 AS 3112
13.8-14.5 See Note
14.5-15.1 See Note
15.8 NEMA 6-20P
13.7 NEMA 6-20P
15.1 AS 3112
12.8-13.4 See Note
13.4-14.0 See Note
15.8 NEMA 6-20P
13.7 NEMA 6-20P
15.1 AS 3112
12.8-13.4 See Note
13.4-14.0 See Note
Amps Plug Configuration
19.4 NEMA 6-30P
16.8 NEMA 6-30P
8
SPECIFICATIONS
Shipping Weight
24 kg (52 lbs.)
24 kg (52 lbs.)
24 kg (52 lbs.)
24 kg (52 lbs.)
24 kg (52 lbs.)
24 kg (52 lbs.)
24 kg (52 lbs.)
24 kg (52 lbs.)
24 kg (52 lbs.)
24 kg (52 lbs.)
24 kg (52 lbs.)
24 kg (52 lbs.)
24 kg (52 lbs.)
24 kg (52 lbs.)
24 kg (52 lbs.)
24 kg (52 lbs.)
24 kg (52 lbs.)
24 kg (52 lbs.)
24 kg (52 lbs.)
24 kg (52 lbs.)
24 kg (52 lbs.)
Shipping Weight
24 kg (52 lbs.)
24 kg (52 lbs.)
Form No. TQ2CEM-0903
